Product Description:

The CSB01.1C-C0-ENS-NNN-L1-S-NN-FW is a drive controller card produced by Bosch Rexroth Indramat within the CSB Drive Controllers series. It manages motor motion and exchanges position, speed, and diagnostic data with higher-level automation equipment. Used inside IndraDrive power sections, the board supplies the motion-control logic needed to coordinate servo or asynchronous motors with plant sequencing tasks. As the control section of the drive, it interprets command values, monitors operating status, and supports closed-loop behavior for the connected axis. This role suits automated handling, packaging, and other equipment that depends on accurate motion control.

This card uses a single-axis architecture, which suits machines that assign one drive to one motion group. Command traffic is handled through CANopen / DeviceNet, allowing parameter access from PLCs without extra gateways and supporting straightforward network integration. The fieldbus link also supports the exchange of operating values and status information needed by the higher-level controller. Discrete signaling passes through integrated digital I/O points for real-time start, stop, and limit commands, and the feedback input accepts differential encoder signals at 1 Vpp, 5 V TTL levels. Application data can be stored or restored through the front-mounted MultiMediaCard slot, which helps preserve settings when service data needs to be transferred.

The motor feedback port is compatible with IndraDyn / Hiperface protocols, allowing the drive to read absolute position values without extra converters. Option bays accept modules for encoder, analog I/O, and emulation, so the same base card can support test stands or process lines that need added sensing or signal handling. Local interaction is provided by a standard operator panel, which gives menu-driven access to alarms and jog functions without requiring a separate external interface for basic local access. Serial diagnostics remain available through RS232 for legacy tools, and an integrated relay output provides a form-C contact for drive-ready signaling to external circuits.
