CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW

  • Rated 4.5 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911347715
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options

The CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW control unit is manufactured by Bosch Rexroth Indramat. The unit utilizes PROFIBUS as its form of master communication, and it is equipped with various interface options including Encoder HSF/RSF and Encoder EnDat 2.1/1Vpp/TLL.

✓ In-Stock!

Wake Industrial LLC is not an authorized distributor of this product.

CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW

  • Rated 4.5 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911347715
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options

The CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW control unit is manufactured by Bosch Rexroth Indramat. The unit utilizes PROFIBUS as its form of master communication, and it is equipped with various interface options including Encoder HSF/RSF and Encoder EnDat 2.1/1Vpp/TLL.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW basic universal control section manufactured by Bosch Rexroth has a line code of 01. This double axis section has a type plate attached to it highlighting its type designation. This product incorporates a dedicated slot to insert a memory card. The digital inputs and outputs of the device require the connection of an external supply voltage. The unit has two digital inputs each of Type 2 and Type 3 that can be configured as probe. Its probe inputs have a 24V voltage rating and 3mA current rating. The control section has a size of 322.6 x 103 x 49.5mm. The firmware associated with the section must be procured as a separate subitem.

The product features isolated inputs/outputs at its X31 and X32 connectors. These inputs/outputs require a separate power supply connection. The device has a maximum pulse width of 60ms. The modules fitted in its optional slots have individual power consumption ratings. The serial interface of this control section has one node and supports a maximum transmission rate of 115k Baud. The section incorporates a Safe Motion optional module that permits multiple application-related safety functions like safe inputs/outputs, safe direction, safe communication, safe maximum speed and more. The dual-axis control section is backed by a one-year warranty tag.

The device has an EnDat 2.1 / 1Vpp / TTL encoder on its X2 connector. This encoder comprises a maximum output current rating of 35mA and a DC load resistance of 35 Ohms. The control section features spring terminals and screw terminal blocks at its connection points. It is recommended to use wire ends without ferrules when wiring spring terminals. The wire ends must have a stripped length of 10mm when assembling the connections. This control section is shipped across the globe in custom military-grade packaging to avoid the possibility of damage during transit.





  • CDB011CPBEN1EN1EN2EN2S2SNNFW
  • CDB01 1C PB EN1 EN1 EN2 EN2 S2 S NN FW
  • cdb01.1c-pb-en1-en1-en2-en2-s2-s-nn-fw
  • CDB1.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW

CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW Technical Specifications

Master Communication: PROFIBUS
Option 1: Encoder HSF/RSF
Option 2: Encoder HSF/RSF
Option 3: Encoder EnDat 2.1/1Vpp/TLL
