Product Description

The CDB01.1C-PB-EN1-EN1-EN2-EN2-NN-S-NN-FW basic universal double-axis control section from Bosch Rexroth is used in the manufacturer’s drive controller. This control section has to be plugged inside the power section. The associated drive controller is used with a motor to control and monitor its operation. The product is prone to the risk of damage due to improper handling. The device belongs to the CDB product group of such offerings. It has four optional slots to insert additional modules. The unit deploys a PROFIBUS module for master communication. This module is connected to the 9-pin D-Sub female X30 connector of the section and encompasses an LED.

This control section supports configuration ability. The product comes with a circular 8-pole RS 232 serial interface. This interface helps in programming, diagnosis and parameterizing at the time of commissioning and servicing. The section cannot be operated with the VCP01.2 comfort control panel. The product portrays an HSF / RSF encoder as its optional module on its X4.1 connector. The encoder has a supply voltage of 8VDC or 12VAC peak-to-peak. The device must always be mounted and dismounted only by people who are trained to do so. The unit supports a limited number of plug-in actions. This CDB01.1C-PB-EN1-EN1-EN2-EN2-NN-S-NN-FW section is available with a one-year warranty.

The product is intended to be operated in industrial environments and has to be used only as intended. The device should be put to use only with accessories and spare parts that have the approval of the manufacturer. The unit must never be operated underwater. The drive controller is meant to be switched ON only after its equipment grounding conductor has been permanently connected. The basic universal section features switching frequencies of 2kHz, 4kHz and 8kHz. It tends to have a very hot external surface during operation. The control section can be sent to the desired destination in any country.
