BTV04.2GN-FW

  • Rated 4.4 (24 total ratings)
  • MPN: R911282182
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
BTV04 Miniature Control Panel manufactured by Bosch Rexroth Indramat. This Panel features a Graphics Capability, 128 X 64 Pixel Display and uses a Standard Keyboard.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock! BTV04.2GN-FW | Bosch Rexroth Indramat BTV04 Miniature Control Panel Series | Image

BTV04.2GN-FW

  • Rated 4.4 (24 total ratings)
  • MPN: R911282182
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
BTV04 Miniature Control Panel manufactured by Bosch Rexroth Indramat. This Panel features a Graphics Capability, 128 X 64 Pixel Display and uses a Standard Keyboard.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a BTV04.2GN-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The BTV04.2GN-FW is a miniature control panel manufactured and produced by Bosch Rexroth Indramat. The company, Indramat, is a worldwide leading company in the automations and machinery industry. While the company is originally from Germany, the innovations and products produced by Rexroth has given their business an international reputation within the industrial automations industry. Composed of small companies that have merged together over the last few decades, Indramat has an impressive amount of quality experience producing control panels, servo motors and many more industrial products.

The BTV04.2GN-FW is an innovative miniature control panel that is convenient and easy to use. The number pad on the miniature control panel has been reduced to only the most necessary buttons and functions making the BTV04.2GN-FW straightforward and simple to navigate. The graphical user interface is also easy to use for machine handling and especially convenient for the user to use. Another valuable built in function is the ability to self-program seven of the keys. This is especially useful as you are able to write in programs for your companies specific needs.

For added convenience, this product comes with insert slips for the keys that are programmed. This allows the user of the BTV04.2GN-FW to name their function as required.





  • BTV-04.2GN-FW
  • BTV04.2-GN-FW
  • BTV04.2GN FW
  • BTV042GNFW
  • BTVO4.2GN-FW
  • BTV4.2GN-FW

BTV04.2GN-FW Technical Specifications

Product: BTV
Front Panel Material: Aluminum
Line: 4
Design: 2
Display: Graphics Capability, 128 X 64 Pixel
Keyboard: Standard
Firmware: Factory Assigned, must be ordered separately
Serial Interface: RS 485 and RS 232
Programming Support: Function of Seven Keys
Applications: Automation and Handling, Machine Tools

Frequently Asked Questions about BTV04.2GN-FW


Q: How many keys does the BTV04.2GN-FW have on its front panel?

A: The BTV04.2GN-FW has 38 keys on its front panel. Among these keys, 16 keys are machine control keys.

Q: What is the memory of the BTV04.2GN-FW?

A: The BTV04.2GN-FW has two types of memory comprising RAM and flash memory. It has 512 KB RAM and 1 MB flash memory.

Q: What is the protection rating of the BTV04.2GN-FW enclosure?

A: The BTV04.2GN-FW enclosure has IP 65 degree of protection. This protection rating offers complete protection against the pentration of dust and water.

Q: How many inputs does the BTV04.2GN-FW have?

A: The BTV04.2GN-FW has 10 inputs. They have a voltage rating of 24 V.

Q: How many outputs does the BTV04.2GN-FW have?

A: The BTV04.2GN-FW has 11 outputs. The outputs have 24 V voltage rating.

Internal Product Review

  • ‘‘The BTV04.2GN-FW has a compact size and is easy to handle. It has a clearly structured keypad with only minimum number of keys for the most essential functions.’’
