BTM15 Machine Operator Panels
Buy Repair

The BTM15 Machine Operator Panels from Bosch Rexroth Indramat are modular machine user terminals designed for installation on the front panel of a machine.

The series is built around a module carrier with five configurable module positions, allowing the panel to be tailored to different operator-control requirements. Available module functions include items such as emergency-stop, quick-stop, spindle override, feed override, keyboard, handwheel, and machine operating mode selections, along with blind-plate positions where needed. For control integration, the BTM15 provides 16 PLC inputs and 16 PLC outputs and communicates through an INTERBUS-S remote bus connection. The units are built for industrial use with an IP65 front panel, an IP00 housing, approximate dimensions of 407 x 169 x 100 mm, a weight of about 2 kg, and a light gray RAL 7035 finish.

BTM15 Machine Operator Panels
BTM15.2-BA-BA-BA-BA-NA-2EA BTM15.2-BA-TA-BA-TA-RA-2EA BTM15.2-BA-TA-BA-WE-HA-2EA BTM15.2-BA-TA-TA-BA-HA-2EA BTM15.2-BA-TA-TA-VA-BA-2EA BTM15.2-BA-TA-TA-VA-HA-2EA BTM15.2-BA-VA-SA-TA-TA-2EA BTM15.2-NA-BA-BA-BA-TA-2EA BTM15.2-NA-BA-TA-BA-VA-2EA BTM15.2-NA-TA-BA-BA-HA-2EA BTM15.2-NA-TA-BA-TA-VA-2EA BTM15.2-NA-TA-SA-VA-25A BTM15.2-NA-TA-TA-BA-BA-2EA BTM15.2-NA-TA-TA-BA-RA-2EA BTM15.2-NA-TA-TA-BA-SA-2EA BTM15.2-NA-TA-TA-BA-VA-2EA BTM15.2-NA-TA-TA-SA-VA-2EA BTM15.2-NA-TA-TA-SA-VR-2EA BTM15.2-NA-TA-TA-TA-BA-2EA BTM15.2-NA-TA-TA-TA-HA-2EA BTM15.2-NA-TA-TA-TA-RA-2EA BTM15.2-NA-TA-TA-TA-TA-2EA BTM15.2-NA-TA-TA-TA-VA-2EA BTM15.2-NA-TA-TA-VA-BA-2EA BTM15.2-NA-TA-TA-VA-HA-2EA BTM15.2-NA-TA-TA-VA-RA-2EA BTM15.2-NA-TA-TA-VA-SA-2EA BTM15.2-NA-TA-TA-VA-TA-2EA BTM15.2-NA-TA-TA-VA-VA-2EA BTM15.2-NA-TA-TA-VB-SA-2EA BTM15.2-NA-TA-VA-SA-HA-2EA BTM15.2-NA-TA-VB-WE-HA-2EA BTM15.2-NA-TA-VB-WE-VB-2EA BTM15.2-NA-VA-SA-TA-TA-2EA BTM15.2-NA-VA-TA-TA-HA-2EA BTM15.2-NA-VA-VA-TA-BA-2EA BTM15.2-NA-VA-VA-TA-VA-2EA BTM15.2-NB-SA-VB-BA-HA-2EA BTM15.2-NB-TA-TA-BA-VA-2EA BTM15.2-NB-TA-TA-SA-VA-2EA BTM15.2-NB-TA-TA-TA-BA-2EA BTM15.2-NB-TA-TA-TA-VA-2EA BTM15.2-NB-TA-TA-VA-BA-2EA BTM15.2-NB-TA-TA-VA-HA-2EA BTM15.2-NB-TA-TA-VA-RA-2EA BTM15.2-NB-TA-TA-VA-SA-2EA BTM15.2-NB-TA-VA-VB-BA-2EA BTM15.2-NB-VA-SA-TA-HA-2EA BTM15.2-NB-VA-SA-WE-TA-2EA BTM15.2-NB-VA-TA-TA-BA-2EA BTM15.2-NB-VB-SA-TA-HA-2EA BTM15.2-RA-TA-TA-TA-NA-2EA BTM15.2-RA-VB-SA-TA-HA-2EA BTM15.2-RB-TA-BA-BA-NC-2EA BTM15.2-RB-TA-TA-BA-NC-2EA BTM15.2-TA-BA-BA-BA-NA-2EA BTM15.2-TA-BA-BA-VA-NC-2EA BTM15.2-TA-TA-BA-VA-NC-2EA BTM15.2-TA-TA-SA-VA-HA-2EA BTM15.2-TA-TA-TA-BA-NA-2EA BTM15.2-TA-TA-TA-BA-VA-2EA BTM15.2-TA-TA-TA-SA-HA-2EA BTM15.2-TA-TA-TA-SA-VA-2EA BTM15.2-TA-TA-TA-TA-HA-2EA BTM15.2-TA-TA-TA-TA-NA-2EA BTM15.2-TA-TA-TA-TA-TA-2EA BTM15.2-TA-TA-TA-TA-VA-2EA BTM15.2-TA-TA-TA-VA-NA-2EA BTM15.2-TA-TA-TA-VA-NB-2EA BTM15.2-TA-TA-TA-VA-NC-2EA BTM15.2-TA-TA-TA-VA-SA-2EA BTM15.2-TA-TA-TA-VA-VA-2EA BTM15.2-TA-TA-VA-BA-BA-2EA BTM15.2-TA-TA-VA-SA-HA-2EA BTM15.2-TA-TA-VA-SA-NA-2EA BTM15.2-TA-TA-VA-SA-NC-2EA BTM15.2-TA-TA-VA-TA-TA-2EA BTM15.2-TA-VA-TA-SA-NA-2EA BTM15.2-TA-VA-TA-TA-NA-2EA BTM15.2-TA-VA-TA-TA-NC-2EA BTM15.2-TA-VA-TA-WE-MA-2EA BTM15.2-VB-TA-TA-BA-VB-2EA BTM15.2-VB-TA-TA-TA-HA-2EA BTM15.2-TA-VA-TA-BA-NA-2EA  BTM15.2-TA-TA-T-SA-VA-2EA BTM15.2-NA
