BTA16.1-NA-WA-VE-BS
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911295168
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat BTA16.1-NA-WA-VE-BS is part of the BTA16 Machine Control Boards and features a compact 16mm bore size. This double-acting actuator is crafted with an aluminum body and a stainless steel rod, designed to handle a maximum pressure of 10 bar. Its operating temperature range spans from -20°C to +80°C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Rexroth Indramat BTA16.1-NA-WA-VE-BS Operator Panel is a compact industrial control unit designed for robust machine interface operations. It is equipped with flexible communication ports, integrated safety features, and digital input/output support for automation environments. Its modular design ensures simple installation and connectivity for control systems.
This BTA16.1-NA-WA-VE-BS operator panel provides a wide range of interface options including 1 x RS232 IN, 1 x RS422 IN, 1 x RS422 OUT, 1 x INTERBUS IN, and 1 x INTERBUS OUT. For input handling, it supports 24 V inputs with a low level between 0 – 10 V and a high level between 18 – 30 V, drawing less than 10 mA current. It offers eight isolated 24 V digital I/Os where each 24 V output can deliver up to 200 mA of current. The integrated INTERBUS adapter manages active electronics and supports an I/O width of three words. It supports external connections such as signal lamps through these outputs. Two emergency stop and three enabling circuits are available for mobile operator terminals that are mountable on either side. The E-STOP circuit has a switching voltage of up to 24 V DC or 42 V AC and a switching current of 2 A DC or 3 A AC. The enabling circuit supports the same electrical limits. The air pressure operational range is between 860 to 1060 hPa that is suitable for use at elevations up to 1500 meters.
The BTA16.1-NA-WA-VE-BS operator panel also features an integrated interface converter that links the RS232 interface of the control with the RS422 interface of operator terminals like BTV05.2 and BTC06.2. This eliminates the need for an external interface board. It supports freely configurable modules for safety operations.
Frequently Asked Questions about BTA16.1-NA-WA-VE-BS:
Q: Does the BTA16.1-NA-WA-VE-BS support isolated outputs for peripheral components?
A: Yes, the BTA16.1-NA-WA-VE-BS operator panel offers eight isolated 24 V digital I/Os. Each output supports up to 200 mA, suitable for external devices like signal lamps.
Q: Can the BTA16.1-NA-WA-VE-BS operator panel handle dual-interface communication setups?
A: Absolutely, it includes RS232 IN, RS422 IN/OUT, and INTERBUS IN/OUT ports. This allows for seamless multi-device connectivity within machine control environments.
Q: How does the BTA16.1-NA-WA-VE-BS simplify terminal communication with controllers?
A: It integrates an interface converter to link RS232 control interfaces with RS422 terminals like BTV05.2 and BTC06.2. No external interface board is required.
Q: Is the emergency stop function in BTA16.1-NA-WA-VE-BS electrically safe for harsh environments?
A: Yes, it features two E-STOP circuits with 24 V DC/42 V AC switching and up to 3 A current. It ensures safety compliance for mobile terminals.
Q: Can BTA16.1-NA-WA-VE-BS operate reliably at higher altitudes or variable pressures?
A: This model works within 860 to 1060 hPa, supporting operation up to 1500 meters. It maintains stable performance in varying industrial altitude conditions.
