ADF164C-B35TC0-AS06-A2V2

  • Rated 4.5 (36 total ratings)
  • MPN: R911309090
  • Call for Expedited Shipping and Product Condition Options
The ADF164C-B35TC0-AS06-A2V2 Main Spindle motor is a part of the ADF series manufactured by Bosch Rexroth. This motor operates with its Output Connector on Side C, Heavy-Duty bearing, a Digital servo motor feedback type, and is Not Equipped with a holding break.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

ADF164C-B35TC0-AS06-A2V2

  • Rated 4.5 (36 total ratings)
  • MPN: R911309090
  • Call for Expedited Shipping and Product Condition Options
The ADF164C-B35TC0-AS06-A2V2 Main Spindle motor is a part of the ADF series manufactured by Bosch Rexroth. This motor operates with its Output Connector on Side C, Heavy-Duty bearing, a Digital servo motor feedback type, and is Not Equipped with a holding break.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a ADF164C-B35TC0-AS06-A2V2 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch ADF164C-B35TC0-AS06-A2V2 is a servo motor with 334 Nm rated torque. Rated speed of the ADF164C-B35TC0-AS06-A2V2 is 2000 RPM. Power rating for the motor is 70 kilowatts. Current rating for the motor is 148 Amps. Two wires having minimum 25 mm2 cross sectional area are recommended for the power connection to the motor. Position of power connector is on the top side of the motor. The power connector is available as a junction box connected to side A of the motor. Maximum rated speed of the ADF164C-B35TC0-AS06-A2V2 is 6000 RPM. Rated power loss of the motor is 6.8 kilowatts. The coolant temperature at the insertion point of the liquid cooled motor should be between 10 and 40 degrees Celsius. Bosch recommends 10 liters per minute coolant throughout to ensure adequate motor cooling. The permissible starting pressure for the coolant is 3 bar.

Motor size of the ADF164C-B35TC0-AS06-A2V2 is 164 and the length of the motor is C. The motor supports flange and foot mounting. The ADF164C-B35TC0-AS06-A2V2 has heavy duty bearings. Shaft sealing ring is not provided for the plain motor shaft. However it can be ordered as an option if required. Digital servo feedback is supported by the ADF164C-B35TC0-AS06-A2V2. The motor does not have a holding brake. ADF motors such as the ADF164C-B35TC0-AS06-A2V2 can be used with ECODRIVE and DIAX04 servo drives. Personnel involved in the storage, transport, installation and operation of the motor should be familiar with safety instructions recommended by Bosch regarding ADF series motors. Faulty motors should not be put in operation. Typical applications for ADF motors include machines tools, metal forming machine tools and foodstuff machines. Control and monitoring of ADF motors may require additional sensors. This unit can be shipped globally with a one-year warranty period from Wake Industrial.

ADF164C-B35TC0-AS06-A2V2 Documents

  • ADF164CB35TC0AS06A2V2
  • adf164c-b35tc0-as06-a2V2
  • ADF164C-B35TCO-ASO6-A2V2

ADF164C-B35TC0-AS06-A2V2 Technical Specifications

Bearing: Heavy-Duty
Holding Brake: Not Equipped
Motor Feedback: Digital servo
Output Connector: Side C
