The ADF104C-B05TA1-BS07-D2N1 Main Spindle motor is a part of the ADF series manufactured by Bosch Rexroth. This motor operates with its Output Connector on Side A, Standard bearing, a Digital servo with integrated multiturn absolute encoder motor feedback type, and is Not Equipped with a holding break.

ADF104C-B05TA1-BS07-D2N1

  • Rated 4.4 (14 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911284500
  • Call for Expedited Shipping and Product Condition Options
The ADF104C-B05TA1-BS07-D2N1 Main Spindle motor is a part of the ADF series manufactured by Bosch Rexroth. This motor operates with its Output Connector on Side A, Standard bearing, a Digital servo with integrated multiturn absolute encoder motor feedback type, and is Not Equipped with a holding break.
Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth provides worldwide services in the manufacturing and maintenance of main spindle motors, controllers, and frequency converters for different automated processes in industries. The company is highly concerned about its Customer satisfaction.

The ADF104C-B05TA1-BS07-D2N1 model comes in a standard design with a C-type length and a net weight of 70 kg. The main spindle motor is dynamically balanced as per balance class R which is 0.71 for 600 to 1800 rpm and 2.8 for 6000 to 8000 rpm. The main spindle motor operates at AC 220V coming from a drive controller to generate the nominal power of 15 kW and torque of 72 Nm while operating at the nominal current of 72 A at 2000 rpm. The moment of inertia of the rotor is 0.023 kgm2. The model comes with a flange mounting which allows IM B5, IM V1, and IM V3 mounting orientations. The model which is mounted in IM V3 orientation will not provide any long-term resistance against the liquid which is collected along the output shaft. The output shaft balanced with the entire key is used in this model with shaft sealing rings to prevent any leakage.

The model ADF104C-B05TA1-BS07-D2N1 is protected by IP65 protection class and insulation class of F. The model comes without any side-B shaft end and holding break. The coolant is used in this model for cooling purposes and to overcome power dissipation of 2.4 kW which is produced due to friction and continuous power generation, the coolant is inserted into the housing through an inlet hole located at side-B. The minimum core diameter of the cables used for electrical connection is 25 mm2 which can be connected to the power connector having an A-side output direction. This unit can be shipped globally with a one-year warranty period from Wake Industrial.

ADF104C-B05TA1-BS07-D2N1 Documents

  • ADF104CB05TA1BS07D2N1
  • adf104c-b05ta1-bs07-d2n1
  • ADF1O4C-BO5TA1-BSO7-D2N1

ADF104C-B05TA1-BS07-D2N1 Technical Specifications

Bearing: Standard
Holding Brake: Not Equipped
Motor Feedback: Digital servo with integrated multiturn absolute encoder
Output Connector: Side A
