2AD134D-B35OB1-CS06-B2V1

  • Rated 4.4 (16 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911285305
    Call for Availability

The 2AD134D-B35OB1-CS06-B2V1 is a synchronous servo motor with a rated voltage of 400 VAC and a rated torque of 27 Nm. Manufactured by Bosch Rexroth Indramat, it is part of the 2AD 3-Phase Induction Motors series. This motor boasts a cooling method of blower (CS06) and a maximum speed of 3000 min⁻¹.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The 2AD134D-B35OB1-CS06-B2V1 is a synchronous servo motor. It is utilized where uniformity of output and reliability of torque are desired. The motor measures 134 mm in frame size and possesses a rated power of 4.2 kW. The rated voltage is 400 VAC, which is the standard industrial power supplies.

It possesses a rated current of 10.5 A and offers effective energy conversion during dynamic operations. With a rated torque of 27 Nm, the motor offers strong rotation torque to perform mechanical work in the medium range. The motor uses a mounting arrangement on the foot denoted as B2V1, offering good and firm support on machine frames or foundations. The motor is of thermal class F, which means that it can run at maximum temperature rise of 105°C, well suited for sustained usage without overheating. The synchronous structure provides smooth rotor speed in synchronism with input frequency and hence is applicable for precise positioning and control. The CS06 winding code improves motor performance and cooling efficiency. Its mechanical structure gives excellent structural strength for continuous operation under. This motor's built-in structure helps low vibration and noise. It improves smoother performance in automatic systems. Its frame size achieves a weighted compromise between mechanical strength and compactness. Its uses typically span from conveyor drives to packaging equipment and other drive systems requiring tight speed control and consistent torque output. It mounts with emphasis on mounting simplification while offering vibration dampening under heavy-duty cycles.

The 2AD134D-B35OB1-CS06-B2V1 can ensure long-term use with minimal maintenance because of superior construction materials and a sealed body with protection against water and dust. It is optimized to work with high-performance drive systems and complies with stringent usage requirements. Generally, this motor provides a predictable solution for applications that need stable power supply, thermal robustness, and precise control.

  • 2AD134D B35OB1 CS06 B2V1
  • 2AD134DB35OB1CS06B2V1
  • 2AD134D-B350B1-CS06-B2V1
  • 2AD134D-B35OB1-CSO6-B2V1
  • 2AD134D-835O81-CS06-82V1
  • 2AD134D-835O81-CSO6-82V1
  • 2AD134DB350B1CS06B2V1
  • 2AD134DB35OB1CSO6B2V1

2AD134D-B35OB1-CS06-B2V1 Technical Specifications

Motor Type: Synchronous Servo Motor
Encoder Type: Resolver
Protection Class: IP65 (shaft with shaft seal)
Thermal Class: F
Weight: 55 kg
Frame Size: 134 mm
Rated Power: 4.2 kW
Rated Voltage: 400 VAC
Rated Current: 10.5 A
Rated Torque: 27 Nm
Max Speed: 3000 min⁻¹
Cooling Method: Blower (CS06)
Mounting Type: Foot mounting (B2V1)

Frequently Asked Questions about 2AD134D-B35OB1-CS06-B2V1


Q: What is the rated power of 2AD134D-B35OB1-CS06-B2V1?

A: The rated power is 4.2 kW.

Q: What encoder is used in 2AD134D-B35OB1-CS06-B2V1?

A: It features a resolver encoder.

Q: What is the cooling type of 2AD134D-B35OB1-CS06-B2V1?

A: It uses a blower cooling method.

Q: What is the rated torque of 2AD134D-B35OB1-CS06-B2V1?

A: The rated torque is 27 Nm.

Q: What mounting style is used in 2AD134D-B35OB1-CS06-B2V1?

A: It is foot-mounted with type B2V1.

Internal Product Review

  • ‘‘The 2AD134D-B35OB1-CS06-B2V1 motor delivers consistent performance across various industrial applications. It handles extended duty cycles without overheating and maintains precise control. Its robust construction ensures longevity in demanding environments. Integration into existing systems is straightforward. This model supports reliable operation, even under fluctuating loads. A dependable choice for continuous service.’’
