EP3184-0002
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The Beckhoff EP3184-0002 is part of the EP Digital Input Series and uses the EtherCAT protocol for communication. This unit features four single-ended inputs, each with a 16-bit resolution and a common-mode voltage of up to 35 V. Its conversion time is approximately 100 microseconds.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Beckhoff EP3184-0002 digital input module delivers precise and versatile data acquisition for industrial applications. As an entry within the EP Digital Input Series, it combines a fast 100 microsecond conversion speed with 16-bit resolution for accurate measurement of process and machine variables. This EtherCAT device accepts diverse analog signal types on its four single-ended voltage/current inputs. Each channel supports both -10 to +10 V and 0/4 to 20 mA input ranges through software parameterization. This flexibility facilitates connecting a wide array of sensors from various manufacturers.
Protection of connected hardware is also emphasized. A maximum 35 V common-mode voltage rating defends against transient spikes or ground faults. M12 connection ports with shielded bus interfaces guard against electromagnetic interference. Communication over an EtherCAT interface allows for highly synchronized multi-node distributed control without special programming. Inputs are monitored and recorded within TwinCAT automation software at lightning speeds achievable only through open industrial standards.
Rugged construction suitable for plant floors sees the module rated for a nominal 24 VDC supply while drawing a modest 120 mA. Compact M8 sensor cabling preserves space in distributed panel architectures. Overall precision, versatility, and real-time performance bring industrial-strength A/D conversion to industrial automation applications. Whether for basic PLCs, robot cells, or condition monitoring systems, the EP3184-0002 handles varied process signals with rapid 16-bit scans. Both engineering teams and line operators can depend on its reliable insights into production processes.
Frequently Asked Questions about EP3184-0002:
Q: What is the resolution of the EP3184-0002?
A: The EP3184-0002 has a resolution of 16 bits, allowing for precise measurements of input signals.
Q: What types of signals can the EP3184-0002 accept?
A: This module supports signals from -10 to +10 V or 0/4 to 20 mA, which can be parameterized per channel for flexibility.
Q: What is the conversion time for the EP3184-0002?
A: The conversion time for the EP3184-0002 is approximately 100 microseconds, ensuring rapid data processing.
Q: What is the maximum common-mode voltage for this module?
A: The EP3184-0002 can handle a maximum common-mode voltage of up to 35 V, providing additional protection for the inputs.
Q: How is the EP3184-0002 powered?
A: The module is powered with a nominal voltage of 24 V DC and has a current consumption of 120 mA from the supply.
