The Beckhoff C6930-0060 is part of the C6 Industrial PC Units series and features an Intel Celeron G3900TE processor with 2 cores running at 2.3 GHz. It offers 4 GB DDR4 RAM, 1 TB 2.5-inch hard disk storage, and a SATA RAID 1 configuration. This unit comes equipped with 2 Ethernet ports, 4 USB 3.0 ports, and a 24 V DC power supply, all enclosed in an IP20-rated housing.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The C6930-0060 is an industrial PC unit manufactured by Beckhoff and assigned to the C6 Industrial PC Units series. Designed for cabinet installation, the device serves as a centralized control and visualization platform in automated machinery, combining PLC logic, motion control, and HMI tasks inside a single compact housing. This arrangement lets one unit handle machine supervision and control tasks that might otherwise be distributed across separate components.
Processing performance comes from an Intel Celeron G3900TE dual-core CPU; its two cores run at 2.3 GHz, providing enough headroom for real-time cycle execution. The controller carries 4 GB DDR4 RAM to buffer application code, fieldbus data, and visualization objects without pagination delays. Two independent Gigabit Ethernet interfaces, presented as 2 x 100/1000BASE-T, are driven by Intel i219 for LAN1 and Intel i210 for LAN2, allowing separation of machine and plant networks. Four USB 3.0 sockets supply up to 900 mA per port for high-speed service tools or external sensors, while a single CFast slot streamlines OS cloning and image recovery. Power is supplied at 24 V DC, matching common control-cabinet distributions and eliminating the need for an internal AC converter.
Local mass storage is organized through SATA RAID 1, implemented with two 2.5-inch drive bays, so mirrored data remain available even if one medium fails. For operating-system images or user archives, the factory configuration installs a 1 TB 2.5-inch Hard Disk; the second bay is left free for a hot spare or incremental backup target. Security functions are anchored by a discrete fTPM 2.0 module, enabling key storage and trusted-boot checks without external tokens. The aluminum housing carries a protection rating of IP20, suitable for clean switchgear environments up to 55 °C when adequate airflow is provided. Two 2.5-inch drive slots, one CFast slot, and dual LAN controllers round out the expansion options so the unit can scale from simple machine cells to networked production lines.
Frequently Asked Questions about C6930-0060:
Q: What processor is used in the C6930-0060 Industrial PC?
A: The C6930-0060 features an Intel Celeron G3900TE processor running at 2.3 GHz.
Q: How much RAM does the C6930-0060 provide?
A: This model is equipped with 4 GB of DDR4 RAM for memory requirements.
Q: What storage capacity is available in the C6930-0060?
A: The C6930-0060 offers a 1 TB 2.5-inch hard disk for storage.
Q: How many Ethernet ports does the C6930-0060 have and what controllers are used?
A: There are two Ethernet ports (100/1000BASE-T) using Intel i219 and i210 controllers on this device.
Q: What is the power supply requirement for the C6930-0060?
A: Power is supplied to the C6930-0060 via a 24 V DC input.
