5AP923.1505-00

  • Rated 4.6 (17 total ratings)
  • Call for Expedited Shipping and Product Condition Options
The 5AP923.1505-00 is manufactured by B&R Automation as part of their Automation Panel Series. This panel is a TFT Color type and had a LED backlight. The panel has a Projected Capacitive Touch screen perfect for the job.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

5AP923.1505-00

  • Rated 4.6 (17 total ratings)
  • Call for Expedited Shipping and Product Condition Options
The 5AP923.1505-00 is manufactured by B&R Automation as part of their Automation Panel Series. This panel is a TFT Color type and had a LED backlight. The panel has a Projected Capacitive Touch screen perfect for the job.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a 5AP923.1505-00 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The B&R 5AP923.1505-00 is an operator panel with a 15-inch display. The panel is compatible with PPC900/PPC2100/PPC3100/PPC2200 systems. It is designed for control cabinet installation. The panel display has a landscape format. The display resolution is XGA (1024 x 768 pixels) and the display is based on TFT technology. The display supports analog resistive touch technology. The display brightness range is 20 to 400 cd/m2. The 5AP923.1505-00 is CE certified. It is also UL certified for industrial control equipment. Front panel of the 5AP923.1505-00 has an IP65 protection rating. The back of the panel is IP20 rated. The front of the panel is for indoor use only. Weight of the 5AP923.1505-00 is 3700 grams. Dimensions of the operator panel are 288 x 370 millimeters. The permitted operating temperature range depends on the relative humidity.

At 95% relative humidity, the operating temperature range is 0 to 40 degrees Celsius. At 10% relative humidity, the operating temperature range is 0 to 60 degrees Celsius. At 95% relative humidity, the storage/transportation temperature range is -20 to 40 degrees Celsius. At 10% relative humidity, the storage/transportation temperature range is -25 to 80 degrees Celsius. The 5AP923.1505-00 is one component of an automation panel. The other component is a link panel that has various graphics interfaces and network connection. Firmware for the 5AP923.1505-00 is upgradable. The PC connected to panel for the firmware upgrade should remain switched on during the firmware upgrade process. B&R only permits use of approved components for maintenance and repair work. The device is only permitted to be cleaned when power is switched off in order to prevent unintended functions from being triggered by touching the touch screen or pressing keys.

  • 5AP9231215-00
  • 5AP923121500
  • 5AP923 1215 00

5AP923.1505-00 Technical Specifications

Backlight Type: LED
Touch Screen Technology: Projected Capacitive Touch
Type: TFT Color
