C6930-0060

  • Rated 4.5 (30 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
    In-Stock, Ships in 3 Days
  • Call for Expedited Shipping and Product Condition Options

C6930-0060 is a C69xx series Control Cabinet Industrial PC manufactured by Beckhoff. At its basic configuration, this PC weighs 2.1 kg and its dimensions (W x H x D) are 3.5" x 9.3" x 4.8". This PC features an Intel? Celeron? G3900TE 2.3 GHz processor and 4 GB DDR4 RAM storage.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Beckhoff’s motion control products include Fieldbus components, I/O platforms, industrial PCs, planetary gear systems, servo motors, and synchronous motors. In addition, the company produces a variety of software packages for augmenting advanced motion control operations.

The C6930-0060 control cabinet PC produced by the firm utilizes the fast Intel Core i3/i5/i7 processors. The industrial PC has a 2.1 kg weight and can be operated without condensation in conditions having up to 95% relative humidity. The system’s power consumption is 32 W and its emitted resistance is in accordance with the EN standards. The PC can mirror two hard discs at a time because it comes with a SATA RAID controller. Two fan cartridges have been provided in the PC’s enclosure that allow the PC to operate at temperatures up to 55 ᵒC. In addition to the fans, cooling fins are also provided in the design that ensures efficient heat transfer. The C6930-0060 comes with multiple LEDs for diagnostics and user awareness. Power, TwinCAT, HDD, fan, and fieldbus error LEDs have been provided.

The C6930-0060 comes with RJ 45 connectors for establishing a connection with LAN. Additionally, PCle is provided through which Ethernet ports can be connected. The system also comes with four USB 2.0 ports and a digital visual interface port for transferring video signals. The device comes with an IP 20 standard protection and is resistant to 5G shocks for a duration of 30 ms. The C6930-0060 can sustain sinusoidal vibrations that are in a range of 10 Hz to 58 Hz. The device also comes with a single RS232 serial interface. As a whole, the C6930-0060 is an ideal platform for machine handling operations.

  • C69300060
  • c6930-0060
  • C693O-OO6O

C6930-0060 Technical Specifications

Compact Dimensions (W x H x D): 3.5 x 9.3" x 4.8""
Maximum permissible installation height: 1000 meters above sea level
Weight : 2.1kg
Processor: Intel Core i3/i5/i7
Power Consumption: 32W
Protection Rating: IP20
Maximum permissible relative humidity: 95%
Maximum permissible ambient temperature : 550C
Cooling : Forced Ventilation
Nominal voltage : 24V

Frequently Asked Questions about C6930-0060


Q: What type of cable should be used to connected the C6930-0060 to the power supply?

A: The connection of the C6930-0060 to the power supply should be done with standardized cables manufactured by Beckoff. Electrical cables that have a maximum cross section of 1.5mm2 is recommended to achieve the lowest possible volatge drop in the supply line.

Q: Are operators allowed to carry out repair operation on the C6930-0060?

A: Repair operations on the C6930-0060 should only be carried out by vendors. Wake industrial generally complete repair operations within 7 to 14 days.

Q: What part of the C6930-0060 require replacement?

A: The C6930-0060 is manufactured from the best materials, however to maintain optimum operation, the Battery, storage media and internal air blower of the drive should be repaired as soon as their service life is exhausted.

Q: Is the C6930-0060 resiatant against industrial vibrations?

A: Despite the robust design of the C6930-0060 unit, the components are sensitive to strong vibration and impacts. The unit can however withstand industrial vibration that come within the range of 10Hz to 58Hz.

Q: what is the proper way to clean the C6930-0060?

A: The C6930-0060 should be cleaned often to prevent the build up of dust and other solid particles. Only cleaning agents specified in the documentation of the drive used be used for cleaning operations.
