The AL2024-0001-0000 is a 3-phase synchronous linear servomotor manufactured by Beckhoff. This device features a maximum speed of 7 m/s, a peak force of 1800 N, and a peak current of 52 A.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

AL2024-0001-0000

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Call for Expedited Shipping and Product Condition Options
The AL2024-0001-0000 is a 3-phase synchronous linear servomotor manufactured by Beckhoff. This device features a maximum speed of 7 m/s, a peak force of 1800 N, and a peak current of 52 A.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a AL2024-0001-0000 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The AL2024-0001-0000 is a linear servo motor that features a peak current of 26.2A in normal winding and 52.0A is speed winding. It has a power constant of 93N/A and a continuous current of 8.60A. The continuous force air cooling is 800N, a peak force is 1800N, and a magnetic motor attraction force is 3400N. The weight of the coil unit is 5.2kg while the magnetic plate weighs 3.8kg/m. the AL2024-0001-0000 can be connected to other servo motors parallel to the controller to achieve higher total current. Use a temperature sensor to identify which motor has the poorest cooling.

Provide a space of 16 mm between servo motors to ensure optimum cooling. During installation you should use M5 steel screws, a tightening torque of 3.0 – 5.0 Nm, and reach a depth of 4 mm to 5 mm. to ensure an efficient servo feedback system, the AL2024-0001-0000 should be coupled with guides, plugs, cables, and a machine bed. The motor comprises a coil unit and a magnetic plate. The coil unit has two models. The N-type and the S type. The S type has a higher energy consumption and a maximum speed.

The AL2024-0001-0000 comes in a brushless three-phase design which is ideal for servo applications. When used with digital servo drives, it becomes ideal for positioning tasks in applications such as transfer lines, machine tools, industrial robots, and handling equipment that require high stability and dynamics. The magnetic plate comprises permanent magnets that offer exceptional motor dynamics. The installation elevation is 1000 meters above sea level, permissible humidity is 95%, and the ambient operating temperature is 5 to 40 degrees. Get this Beckhoff servo motor from Wake Industrial with a one-year warranty.

  • AL2O24-OOO1-OOOO
  • al2024-0001-0000
  • AL202400010000

AL2024-0001-0000 Technical Specifications

Max. Speed: 7 m/s
Peak Current: 52 A
Peak Force: 1800 N
