EEA-PAM-5**-B-32 Power Amplifier Card Series for Proportional Control Valves manufactured by Vickers. The EEA-PAM-571-B-32 Card is For Proportional Valve CVU-**-EFP1 and has a Power Supply Nominal Voltage of 24V DC x 50W.

EEA-PAM-571-B-32

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
EEA-PAM-5**-B-32 Power Amplifier Card Series for Proportional Control Valves manufactured by Vickers. The EEA-PAM-571-B-32 Card is For Proportional Valve CVU-**-EFP1 and has a Power Supply Nominal Voltage of 24V DC x 50W.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a EEA-PAM-571-B-32 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Motion control is an investment that requires you to find reliable and safe products that will last longer and offer matchless performance. And that is what Vickers’s commitment has remained over the years, prioritizing the machine needs of its customers. Whether you are considering supply modules, servo motors, drive controllers, servo drives, gearing, power cables or even gearing, you can conveniently find at Vickers. All these will exhibit extreme ruggedness, innovation, power, and safety. Also, these products are configurable to suit specific application requirements and can accommodate various appliances.

The EEA-PAM-571-B-32 is one of the high-quality amplifiers designed by Vickers to remain powerful and future proof for machine users and designers. The ideal temperature to transport or store the unit is -12 to +185F (-25 to +850C) while the ambient operating temperature is 0 to 500C (32 to 122 F). The unit’s estimated weight is 0.4 kgs and you should strive to prevent signal loss at d2 pin as this occurrence leads to polarity and can cause erratic motion. This will have an adverse effect on performance.

The EEA-PAM-571-B-32 amplifier’s pin z22 for control output has a supply voltage of 15 V but for the LVDTs, while the output voltage for control output at pin z2 is estimated to be 10 V +/- 1% X 5 mA. The voltage at b2 stands at 10V (+/- 1%) x 5 mA. The unit’s voltage control is less than 20 mV.

The EEA-PAM-571-B-32 amplifier’s command signal input’s direct voltage pins include b8, b6, z8, as well as b10. The inverting voltage pin is the z10. This signal input’s voltage is +/-10V while the input voltage (impedance) stands at 47 kΩ.

  • EEA PAM 571 B 32
  • EEA-PAM-57l-B-32
  • EEAPAM571B32

EEA-PAM-571-B-32 Technical Specifications

Series: EEA-PAM-5**-B-32
Control Supply Output:
For Proportional Valve: CVU-**-EFP1
Power Supply Nominal Voltage: 24V DC x 50W
Control Supply Output: 15V
Ramp Acceleration Time Range: With pot. set at zero, 0 to +10V equates to a ramp time range of 50ms to 5s
Ramp Deceleration Time Range: With pot. set at max., 0 to -10V equates to a ramp time of 5s to 50 ms
