DSA 015-230-S

  • Rated 4.3 (35 total ratings)
  • MPN: M.1300.5141
  • Call for Expedited Shipping and Product Condition Options
The DSA 015-230-S is manufactured by Kollmorgen as part of their retired DSA Drive Series. This part features an input voltage of 100-240 Vrms Single Phase and an input frequency of 47-63 Hz. The DSA 015-230-S also holds an AC input current of 9 A rms and a continuous output of 5 A.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DSA 015-230-S

  • Rated 4.3 (35 total ratings)
  • MPN: M.1300.5141
  • Call for Expedited Shipping and Product Condition Options
The DSA 015-230-S is manufactured by Kollmorgen as part of their retired DSA Drive Series. This part features an input voltage of 100-240 Vrms Single Phase and an input frequency of 47-63 Hz. The DSA 015-230-S also holds an AC input current of 9 A rms and a continuous output of 5 A.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a DSA 015-230-S to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DSA 015-230-S belongs to the DSA family of advanced digital servo drives, designed and manufactured by Kollmorgen. It is primarily designed to simplify drive applications with its high performance and flexibility. In addition, this drive can be used with AC sinusoidal brushless motors for noiseless and efficient operations across a variety of industrial applications. It is also effective as an analog servo drive and is a suitable alternative for stepper drives.

The DSA 015-230-S is operated with a single-phase AC supply voltage value within limits of 100 V and 240 V. The required AC input frequency for its operation is within the range of 47 Hz to 63 Hz. Its continuous power output with a 115 V AC input is 0.5 kW. With a 230 V AC input, its continuous power output is 1.0kW. The servo amplifier can also deliver 5A of continuous output current and up to 15A of peak current output. It uses 8 current-sinking digital inputs between 12V to 24V and 4 current sourcing digital outputs within the same voltage range. Its input-output response time is 100 μsec. It can also absorb up to 125 Joules of energy with an AC input of 115 V.

Encoders compatible with the DSA 015-230-S for motor feedback are incremental, multiturn absolute, and single turn (high resolution) encoders. The servo amplifier’s configuration can be done remotely on Kollmorgen’s user-friendly DSAPro software. Troubleshooting and monitoring of the device can also be done on this software. With its SERCOS feature, the DSA 015-230-S communicates at high speed using fiber optics. Environmental requirements for its use are a maximum ambient temperature of 55° C and a 1500 m installation altitude.

  • dsa 015-230-s
  • dsa-015-230-s

DSA 015-230-S Technical Specifications

AC Input Current Nominal: 9 A rms
AC Input Frequency: 47-63 Hz
AC Input Voltage: 100-240 Vrms Single Phase
Continuous Output Current: 5 A
Output Peak Current : 15 A
