The BAF3644-5081-56BC is manufactured by Kollmorgen as part of the BA and BAF Low Voltage Motor Series. It features an HP of 1and a voltage of 24 V. It holds a continuous current of 38.4 A and a torque constant of 1.00 lb-in. Made to undergo a resistance of 0.05 ohms and hold an inductance of 0.21 mH.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

BAF3644-5081-56BC

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Call for Expedited Shipping and Product Condition Options
The BAF3644-5081-56BC is manufactured by Kollmorgen as part of the BA and BAF Low Voltage Motor Series. It features an HP of 1and a voltage of 24 V. It holds a continuous current of 38.4 A and a torque constant of 1.00 lb-in. Made to undergo a resistance of 0.05 ohms and hold an inductance of 0.21 mH.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a BAF3644-5081-56BC to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Featured with NEMA 56C mounting system and sealed bearings the BAF3644-5081-56BC is a permanent magnet DC motor by KOLLMORGEN. You can operate this low voltage motor using a 24 VDC power supply. Moreover, it can also be operated directly through batteries – a provision that makes it an ideal choice for ad-hoc systems. The BAF3644-5081-56BC is rated to produce a maximum of 1 horsepower. This motor can achieve a maximum speed of 1750 revolutions per minute and consumes around 38.4 amperes in continuous mode. With this motor, you can achieve a maximum continuous torque of 36 pounds per inch.

The BAF3644-5081-56BC has a TEFC (Totally Enclosed Fan Cooled) type enclosure. A fan is mounted on the motor`s shaft at the rear end or non-drive end and supplies cooling airflow across motor windings during operation. This motor offers easy replacement of brushes as you can access each brush by removing the relevant brush access cover. The base of the BAF3644-5081-56BC motor can easily be removed with the help of standard tools in case if required. The polyester impregnated armature used in this motor ensures maximum mechanical and electrical integrity. Whereas, H class insulation is used for the protection of windings.

The BAF3644-5081-56BC is one of the finest choices available for low-voltage, low-speed applications where a drive controller is not to be deployed. However, you can also operate this motor with the help of a low-voltage drive controller. Likewise, other KOLLMORGEN products from BA/BAF series the BAF3644-5081-56BC is also a compact motor and it weighs around 28 lbs. and measures around 12.25 inches in length. The low resistance rating of this motor (I.e. 0.05 ohms) indicates its higher degree of efficiency.

BAF3644-5081-56BC Documents

  • BAF3644508156-BC
  • BA-F3644508156-BC
  • BAF3644508156BC

BAF3644-5081-56BC Technical Specifications

Continuous Current: 38.4 A
Continuous Torque : 36.0 lb-in
HP: 1
Inductance : 0.21 mH
Resistance: 0.05 ohms
Torque Constant : 1.00 lb-in
Voltage: 24 V
