TFM 3.1-020-300-W1-1

  • Rated 4.6 (25 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options

Rexroth, Indramat, Bosch Variable Frequency Drive in the TFM Series. This Variable Frequency Drive features a 20 A Current Rating along with a DC Bus Voltage of 300 VDC.

Wake Industrial LLC is not an authorized distributor of this product.

TFM 3.1-020-300-W1-1

  • Rated 4.6 (25 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options

Rexroth, Indramat, Bosch Variable Frequency Drive in the TFM Series. This Variable Frequency Drive features a 20 A Current Rating along with a DC Bus Voltage of 300 VDC.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth is leading the world in the manufacturing and maintenance of different industrial automation equipment. The company’s main concern is about Customer satisfaction through their top-notch products.

The TFM 3.1-020-300-W1-1 model is used to operate an electrical motor by varying the input frequency and supply voltage. The TFM variable frequency drive is also termed as adjustable frequency drive, micro-drive, and variable speed drive. The model operates at the dc-link voltage of 300 VDC with ±15% tolerance and it comes with a built-in blower unit for cooling purposes. The TFM variable frequency drive operates at the continuous current of 20 A. The model helps in operating the motor at different speeds by controlling the input frequency. Before commissioning, the model should be configured according to the required parameters. The model can be used to upgrade the motor control system and you can save up to 70% of energy consumption with the help of TFM. The model provides a cost-effective automation system when used in conjunction with the respective drive controller and motor. The typical applications of the variable frequency drive are machine tools, textile machines, and controlling pumps or compressors.

The model TFM 3.1-020-300-W1-1 comes in IP20 rating and it should be mounted into the control cabinet of IP 54 protection standard. The model can operate ideally between the permissible temperature range of +5 to +45 degree Celsius and it can be installed at the maximum height of 1000 meters. The model can be stored, without any damage, between the temperature range of -30 to +85 degree Celsius. You can order this TFM variable frequency drive from Wake Industrial along with a one-year warranty.

  • TFM 3.1-O2O-3OO-W1-1
  • tfm 3.1-020-300-w1-1
  • TFM 31020300W11

TFM 3.1-020-300-W1-1 Technical Specifications

Cooling Style: Air, internal (with built-in blower)
Current Rating: 20 A
DC Bus Voltage: 300 VDC
Series: 3
Version: 1
