RAC 3.5-150-460-A00-W1-220

  • Rated 4.3 (28 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911256105
  • Stock: In-Stock, Ships 1-2 Days
  • Call for Expedited Shipping and Product Condition Options
RAC Spindle Drive is manufactured by Rexroth, Indramat, Bosch. This drive has a current type of 300 A and a speed set of 10V. This drive also contains connecting terminals X4 and a connection voltage of 460V.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

RAC 3.5-150-460-A00-W1-220

  • Rated 4.3 (28 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911256105
  • Stock: In-Stock, Ships 1-2 Days
  • Call for Expedited Shipping and Product Condition Options
RAC Spindle Drive is manufactured by Rexroth, Indramat, Bosch. This drive has a current type of 300 A and a speed set of 10V. This drive also contains connecting terminals X4 and a connection voltage of 460V.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a RAC 3.5-150-460-A00-W1-220 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The RAC 3.5-150-460-A00-W1-220 main spindle drive controller manufactured by Bosch Rexroth features an AS programming module fitted onto it. The drive controller helps in controlling asynchronous main spindle motors and frameless spindle motors from the manufacturer digitally. Its drives feature high stiffness that makes it a great choice for numerically controlled machine tools. The product is integrated with emergency stop and mains contactor circuits. The device features a control panel with a keypad and a display on its front. The keypad is used to program the individual parameters required for the application and plant during the commissioning process.

The unit is also equipped with a control voltage interface, a motor NTC-resistor interface, a motor power interface and a direct mains interface at its top. The rated power and/or torque values of the controller begin to dip when the installation altitude crosses 1,000m above sea level. The product features a Class F humidity adhering to DIN 40 040 specifications. There must be no condensation of water or dew on the device during operation. It is protected against the entry of foreign objects that have diameters of more than 50mm. The RAC 3.5-150-460-A00-W1-220 product supports a one-year warranty backing.

The design of the control cabinet for mounting the drive controller must be done by taking sufficient safety measures into consideration. The controller is fitted in place on the back wall of the sealed housing using M8 screws. The inbuilt fan used to cool the product when it is operating has a voltage rating of 220VAC and a frequency of 50/60Hz. Its E1-RAC electrical connection accessories kit includes a plug-in terminal for the mains contactor control and a plug-in terminal for the motor NTC-resistor. The device has a continuous power output of 35kW at the motor output shaft. We can deliver the main spindle drive controller to you through shipping partners like UPS.

RAC 3.5-150-460-A00-W1-220 Documents

  • RAC 35150460A00W1220
  • RAC 3 5 150 460 A00 W1 220
  • Rac 3.5-150-460-a00-w1-220

RAC 3.5-150-460-A00-W1-220 Technical Specifications

Connection Voltage: 460AC 400V/50Hz, 3 x AC 460V/60HzV
Continuous regeneration output: 27Kw
Current Type : 150A
Speed set point: analogue(+\- 10Volts)
Additional encoder input: Absent
Aditional Interface : Absent
Additional Bleeder: Absent
Cooling: With built-in fan
Weight: 49Kg
Peak regeneration output: 40Kw

Frequently Asked Questions about RAC 3.5-150-460-A00-W1-220


Q: What does the AS programming mdoule do in the RAC 3.5-150-460-A00-W1-220?

A: The AS programming module is plugged into the RAC 3.5-150-460-A00-W1-220 controller to match the controller to the main spindle motor and implement the main spindle characteristics. A matching programming module is supplied for each spindle drive purchased.

Q: In what condition is the RAC 3.5-150-460-A00-W1-220 packaged for delivery?

A: The RAC 3.5-150-460-A00-W1-220 with all its accessories comes packed in a recylable carton upon delivery. Accessoires are packed in a plastic bag that is losely placed in the carton.

Q: How can I confirm the RAC 3.5-150-460-A00-W1-220 after it is delivered.

A: An original and a copy of the delivery slip is attached to the transport container. A barcode sticker is also attached to the RAC 3.5-150-460-A00-W1-220 packaging for the easy indentification of the product.

Q: Can users store the RAC 3.5-150-460-A00-W1-220 for a long time without use?

A: The long term storage of the RAC 3.5-150-460-A00-W1-220 is permitted. However the drive should be stored in a dry, dust, and impact free environment. Also the permissible ambinet storage temperature falls between -30 to +850C.

Q: Can the RAC 3.5-150-460-A00-W1-220 be operated with the programming module.

A: It is compulsory for the programming module to be inserted into the RAC 3.5-150-460-A00-W1-220 before it can be operated. The programming module contains configuration data that the drive needs for operation.
