NFD03.1-480-016

  • Rated 4.4 (36 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911286918
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
NFD Mains Filter Series Rexroth Indramat Bosch. The NFD03.1-480-016 has a Nominal Voltage of AC 115 to 480 V, and a rated current of 16 A

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

NFD03.1-480-016

  • Rated 4.4 (36 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911286918
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
NFD Mains Filter Series Rexroth Indramat Bosch. The NFD03.1-480-016 has a Nominal Voltage of AC 115 to 480 V, and a rated current of 16 A

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a NFD03.1-480-016 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The NFD03.1-480-016 mains filter manufactured by Bosch Rexroth is deployed with the manufacturer’s HCS02 series of converters. This product comes with a power dissipation of 6.4kW. The device has dimensions of 55 x 220 x 90 mm (W x H x D). The unit helps in lowering the resulting electrical noise output. It eliminates power and mains frequency interferences and can be installed with ease on any DIN rail in switchgear cabinets. The filter can be used in conjunction with a surge protection device. This product is scalable by motor cable length, number of drives and current. The device has a rated continuous current of 16A.

The mains filter can be connected with up to six drives at a time and supports the use of a motor cable with a maximum length of 120m. The device alleviates the harmonics and mains noise on the associated power supply. The unit also protects the drive system from mains spikes. It is a combination of capacitors and inductors. The product helps to attenuate interference to the admissible level and safeguard the electronic control circuit against voltage peaks generated due to various factors. The device is backed by a one-year warranty period. The unit filters the external spikes and transients on the power line.

The product is also known as a line filter. The capacitors in this device do not trigger any short circuit when there is an internal electrical breakdown. The leakage current may increase beyond the turn-off threshold limit if it operates with multiple equipments as a residual current protective device. The filtering effect of this unit can be confirmed only if its permissible throughput rating is not exceeded even when there is a peak loading of the servo drives. This electronic filter is placed between an external line and the electronic equipment. This filter with warranty support for one year is eligible for worldwide shipping.

  • nfd03.1-480-016
  • NFD031480016
  • NFD03 1 480 016
  • NFD3.1-480-016

NFD03.1-480-016 Technical Specifications

Line: 3
Storage and Transportation Temperature range: (-20 to +80) degree centigrade
Power Dissipation: 6.4 kW
Width: 55 mm
Height: 220 mm
Depth: 90 mm
Rated Continuous Current: 16 A
No. of Drives Supported: 6
Maximum Motor Cable Length: 120 m
Maximum Installation Elevation: 1000 MSL

Frequently Asked Questions about NFD03.1-480-016


Q: What series of converters is the NFD03.1-480-016 compatible with?

A: The NFD03.1-480-016 mains filter is designed for use with Bosch Rexroth's HCS02 series of converters.

Q: How does the NFD03.1-480-016 filter help in improving the electrical quality?

A: It reduces electrical noise output, eliminates power and mains frequency interferences, and attenuates interference to permissible levels, thereby safeguarding electronic control circuits from voltage peaks.

Q: Can the NFD03.1-480-016 filter be used alongside a surge protection device?

A: Yes, the filter can be used in conjunction with a surge protection device for enhanced protection.

Q: What happens to the capacitors in this NFD03.1-480-016 filter during an internal electrical breakdown?

A: The capacitors in the NFD03.1-480-016 do not cause a short circuit when there's an internal electrical breakdown.

Q: How can one confirm the effective filtering of the NFD03.1-480-016 unit?

A: The filtering effect can be ascertained if its permissible throughput rating is not exceeded, even under peak loading of the servo drives.

Internal Product Review

  • ‘‘The NFD03.1-480-016 demonstrates reliable noise attenuation, seamlessly integrating with various converters. Its DIN rail adaptability and protective capabilities against mains spikes make it a noteworthy product in any lineup.’’
