MKE118B-024-PP0-KUN

  • Rated 4.7 (9 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911319418
  • Call for Expedited Shipping and Product Condition Options
The MKE118B-024-PP0-KUN Magnet Motor is manufactured by Rexroth, Indramat, Bosch. This motor has a 118 encoder and a shaft Shaft with key acc. to DIN 6885-1 (with shaft sealing ring). This motor is Without Holding Brake

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

MKE118B-024-PP0-KUN

  • Rated 4.7 (9 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911319418
  • Call for Expedited Shipping and Product Condition Options
The MKE118B-024-PP0-KUN Magnet Motor is manufactured by Rexroth, Indramat, Bosch. This motor has a 118 encoder and a shaft Shaft with key acc. to DIN 6885-1 (with shaft sealing ring). This motor is Without Holding Brake

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a MKE118B-024-PP0-KUN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch MKE118B-024-PP0-KUN is a synchronous motor that has been designed for potentially explosive areas. MKE motors can have housings designed according to the UL or ATEX standard. The MKE118B-024-PP0-KUN motor has a housing that complies with the UL standard. The code for the winding on the motor is 024. The motor frame size is 118. The motor continuous torque at standstill for the 60 K condition is 28 Nm. The maximum torque for the MKE118B-024-PP0-KUN is 102 Nm. The maximum motor current rating is 69.1 Amps. The continuous current at standstill for the 60 K condition is 15.3 Amps. The discharge capacity of the component is 10.3 nanofarads. The winding on the MKE118B-024-PP0-KUN motor has 7.6 Ohms resistance and 0.58 millihenry inductance. The maximum velocity of the motor is 4000 RPM.

Protection category of the MKE118B-024-PP0-KUN is IP65. This protection rating enables motor use very close to the operation machines, which enables cost reduction as switch cabinets are not required. Motor mounting near the machines also reduces cable runs, which also enables cost reductions. The amount of ambient noise produced by a working MKE118B-024-PP0-KUN motor can go up to 61.1 dB. The shaft on the motor has a keyway and a sealing ring. The shaft seal protects the motor and enhances operating life. The shaft seal also required periodic replacement. The motor does not feature a holding brake. The motor has a cable entry diameter as per the US standard. Electrical connections can be accessed on a terminal box located on the top side of the motor. Handling and operating high power electrical machines requires proper training. Therefore only qualified personnel should operate the motor. This unit can be shipped globally with a one-year warranty period from Wake Industrial.

MKE118B-024-PP0-KUN Documents

  • MKE118B024PP0KUN
  • MKE118B 024 PP0 KUN
  • mke118b-024-pp0-kun

MKE118B-024-PP0-KUN Technical Specifications

Holding Brake: Without Holding Brake
Maximum speed: 4000 rpm
Continuous current at standstill 60 K: 15.3 A
Continuous torque at standstill 60 K: 28 Nm
Maximum torque: 102 Nm
Maximum current: 69.1 A
Torque constant at 20 °C: 2.12 Nm/A
Discharge capacity of the compo‐ nent: 10.3 nF
Number of pole pairs: 4
Mass: 45 kg

Frequently Asked Questions about MKE118B-024-PP0-KUN


Q: Can the motor be used among dangerous ambient conditions?

A: Yes, this model can be used in areas where the external environments are potentially explosive. This makes this motor an ideal choice for areas where safety is a priority.

Q: What are the noise levels of this model?

A: This motor produces ambient noise up to 61 db(A) that is safe for expsoure to human ears for long time periods.

Q: Is the motor protected from the penetration of fluids?

A: Yes, the MKE118B-024-PP0-KUN is protected against the incursion of water jets, oils, and emulsions.

Q: What is the lifespan of the motor's shaft seal?

A: Altough the shaft seal enhances the operational life of the motor, it requires periodic maintenance to remain effective. The replacement interval of the seal is subject to use conditions.

Q: Are there any separate electrical connectors with this model?

A: Yes, the MKE118B-024-PP0-KUN comes with electrical connections that are accesible through the terminal box installed in the top.

Internal Product Review

  • ‘‘The MKE118B-024-PP0-KUN stands out because of its compatibility with explosive environments. The motor can be closely mounted with machines without the need of costly control cabinets or switches.’’
