Product Description:

The MKE096B-047-GG0-KN belongs to the MKE Synchronous Motors series produced by Bosch Rexroth Indramat. It is a three-phase servo unit intended to drive machines located in hazardous zones where ignition-capable surface temperatures must be avoided. Using closed-loop speed and position control, the motor converts inverter output into precise torque so that conveying, dosing, or machining equipment can operate with repeatable motion profiles in industrial automation cells.

The electrical package is identified by winding code 047, which indicates the motor’s rated voltage constant, current draw, and thermal losses for use with compatible Rexroth drive controllers. Power and feedback conductors exit at the top of the housing, which helps when cables are routed upward inside a cabinet. All terminals are grouped inside a cast-metal terminal box, providing a sealed chamber that helps shield connection points from conductive dust or oil mist. The motor is supplied without a holding brake, so any static load must be secured through an external mechanical lock or drive torque during power-off conditions. For applications that require smooth coupling to gear stages or couplings, the rotor uses a plain shaft, so no keyway is present to introduce backlash or stress concentrations.

This motor is certified as a servo motor for potentially explosive areas, so its surface temperature classification supports installation in zones with flammable gases. Accurate mechanical alignment to the driven element is aided by a frontal centering hole machined to ISO fit tolerances. A factory-installed shaft seal helps block vapor or fluid ingress along the journal, maintaining the IP protection level where the shaft passes through a pressurized or washdown boundary. External attachments can be fastened to the rotor end using the DIN 332 DS thread, enabling secure attachment of clamping sets, alignment screws, or transport eyes without reworking the shaft.
