The MKD112A-058-KG0-AN servo motor is a part of the MKD Servo Motor Series manufactured by Bosch Rexroth. This motor's winding code is 058, it incorporates Resolver feedback with integrated multiturn absolute encoder, operates with a Plain Shaft and is Not Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

MKD112A-058-KG0-AN

  • Rated 4.4 (34 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911297804
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The MKD112A-058-KG0-AN servo motor is a part of the MKD Servo Motor Series manufactured by Bosch Rexroth. This motor's winding code is 058, it incorporates Resolver feedback with integrated multiturn absolute encoder, operates with a Plain Shaft and is Not Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a MKD112A-058-KG0-AN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MKD112A-058-KG0-AN by Bosch Rexroth is a dynamic synchronous AC motor, with a characteristic speed of 4000 min-1. Its motor length is B and motor size is 112. The weight of this model is 23 kgs, and it features four pole pairs. Its peak current rating is 77 A and rated speed equals 3500 min-1. In addition, the maximum speed of the MKD112A-058-KG0-AN is 4500 min-1. It has a thermal time constant of 40 minutes and a min. strand cross-section of 1.5 mm2.

The MKD112A-058-KG0-AN utilizes an AC excited electromagnetic transducer (resolver) for velocity and position feedback applications. Additionally, the resolver feedback of this equipment is with integrated multiturn-absolute encoder. The design of the MKD112A-058-KG0-AN does not include a holding brake. It also has an electrical commutation feature that lets it carry out a continuous stop/start operation on high and repetitive frequencies. It features a 100 % enclosed motor design, with IP 65 protection class. In addition, this AC motor is suitable for use under harsh environmental conditions. The driven shaft of the MKD112A-058-KG0-AN is plain and has a sealing ring. It is suitable for installation in any preferred position and insulation class is F.

The MKD112A-058-KG0-AN is highly reliable and dynamic owing to its favourable inertia-mass to torque ratio. It comes with a sophisticated temperature monitoring system for overload protection. The flange design on this equipment eases machine attachments and is in accordance with DIN 42948 standards. At 20 degrees Celsius, the MKD112A-058-KG0-AN has a torque constant rated at 0.98 Nm/A. Also, the winding resistance and winding inductance of this MKD motor is 0.86 Ohms (20 oC) and 7.8 mH respectively.   This unit can be shipped globally with a one-year warranty period from Wake Industrial.

MKD112A-058-KG0-AN Documents

  • MKD112A058KG0AN
  • MKD112A 058 KG0 AN
  • mkd112a-058-kg0-an

MKD112A-058-KG0-AN Technical Specifications

Driven Shaft: Plain Shaft
Holding Brake: Not Equipped
Motor Feedback: Resolver feedback with integrated multiturn absolute encoder
Windings Code: 058
