Product Description

The Bosch Rexroth MKD093B-035-KG1-RF is a servomotor. It belongs to MKD product line which is a series of synchronous motors that can be used in conjunction with Rexroth drive controllers for industrial applications including automation, machine tools and the food industry. MKD motors offer several benefits including high operational reliability, overload protection and maximum torque which is usable across a wide motor speed range. The MKD093B-035-KG1-RF is a three-phase permanent magnet motor rated for 4500 RPM. It includes a 22 Nm rated holding brake. Weight of the motor is 20.1 kilograms. The motor housing has IP 65 environmental protection rating. The motor shaft is plain and includes a sealing ring. Feedback is supported on the MKD093B-035-KG1-RF through a resolver feedback with integrated multiturn absolute encoder. In convection cooled mode the motor torque rating is 17.5 Nm and the current rating is 12.8 Amps.

In liquid cooled mode, the torque rating for the MKD093B-035-KG1-RF is 33.3 Nm and the current rating is 24.3 Amps. Winding code for the motor is 035. The permissible temperature for storage and transport is from -20 to 80 degrees Celsius. For optimal motor operation, Bosch recommends the following ambient conditions: maximum installation altitude of 1000 meters and ambient temperature range of 0 to 40 degrees Celsius. Insulation class of the MKD093B-035-KG1-RF is F as per DIN VDE 0530 part 1. Housing of the MKD093B-035-KG1-RF is painted in prime black coat. The motor is designed for industrial applications according to the operating and safety guidelines provided in the manufacturer documentation. Bosch Rexroth will not accept any liability if the MKD093B-035-KG1-RF is used for non-intended purposes which lead to damage or injury to personnel. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
