MKD090B-035-KG1-KN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911272643
  • Stock: Call for Quote
The MKD090B-035-KG1-KN Servo Motor Series is manufactured by Rexroth Indramat Bosch. This motor has a Windings Code of 35 and a Multiturn Motor Encoder. This motor also is A Plain Driven Shaft and is Equipped with a Holding Brake.

MKD090B-035-KG1-KN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911272643
  • Stock: Call for Quote
The MKD090B-035-KG1-KN Servo Motor Series is manufactured by Rexroth Indramat Bosch. This motor has a Windings Code of 35 and a Multiturn Motor Encoder. This motor also is A Plain Driven Shaft and is Equipped with a Holding Brake.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MKD090B-035-KG1-KN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Rexroth Bosch group is one of the leading companies in drive and control solutions. With its cutting edge technology comes a solution for the mechanical, electrical and engineering industries. The innovation of the MKD090B-035-KG1-KN synchronous motors comes with an optimized electromagnetic effect which enables the reduction of torque ripple. This is important as it maintains constant path velocity thus increasing the quality of the product.

MKD090B-035-KG1-KN synchronous motors have a maximum set up height of 1000 m above NN with a minimum strand cross-section of 1 mm2. The motor mass is 14, 0 kg with a rated speed of 3000 mm-1 and a maximum speed of 5000 min-1.  Thanks to the optimal winding resistance of 1, 88 Ω and a winding inductance of 15, 5 mH on 4 pole pairs, the motor reduces internal losses.

The permanent storage and transport temperature for the MKD090B-035-KG1-KN synchronous motors range from  -20 to +80 degrees Celsius with a permissible ambient temperature that ranges from 0 to 40 degrees Celsius.  The motor has an insulation class of F according to  DIN VDE 0530 part 1 with a housing coat of prime black in a/w RAL 9005 given that the encoder and power cables are properly mounted. The rated frequency of the motor on any cooling system is 2000 Hz while its peak current is 49, 5 A on any cooling system.  The theoretical maximum torque on any cooling method is 43, 4 Nm. The MKD090B-035-KG1-KN synchronous motors have a voltage constant of 111V/1000 min-1 and a torque constant of   1, 22 Nm/A. If the limits as specified above are exceeded, the operation data must be reduced if found necessary.



MKD090B-035-KG1-KN Documents

  • MKD 090B-035-KG1-KN
  • MKD-090B-035-KG1-KN
  • MKD090B035KG1KN
  • MKDO9OB-O35-KG1-KN
  • MKD090B 035 KG1 KN
  • mkd090b-035-kg1-kn

MKD090B-035-KG1-KN Technical Specifications

Driven Shaft: A Plain
Equipped: Holding Brake
Motor Encoder: Multiturn
Synchronous Servo Motor: MKD
Windings Code: 35
Motor Frame Size: 90
Motor Length: 12.0 Nm
Windings Code: 35
Motor Feedback: Resolver Feedback with integrated multiturn absolute encoder
Driven Shaft: shaft (with shaft sealing ring)
Holding Brake: with holding brake 22 Nm
Output Direction of Power Connection: connection box
Other Design: none
