MDD112C-N-030-N2M-130PA0

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911257815
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
The MDD112C-N-030-N2M-130PA0 Servo Motor is manufactured by Rexroth Indramat Bosch. This motor has a Standard Housing Design , a 3000 Min Nominal Speed, a(n) Multiturn Absolute Motor Feedback, and an Output Shaft With Shaft Sealing. This Motor is also Not Equipped with a Blocking Brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

MDD112C-N-030-N2M-130PA0

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911257815
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
The MDD112C-N-030-N2M-130PA0 Servo Motor is manufactured by Rexroth Indramat Bosch. This motor has a Standard Housing Design , a 3000 Min Nominal Speed, a(n) Multiturn Absolute Motor Feedback, and an Output Shaft With Shaft Sealing. This Motor is also Not Equipped with a Blocking Brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MDD112C-N-030-N2M-130PA0 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MDD112C-N-030-N2M-130PA0 by Bosch Rexroth Indramat belongs to the family of MDD synchronous motors and has a size of 112, a length of C, and is 48 kilograms in weight. It outputs a nominal speed of 3000 revolutions per minute and is without a blocking brake. It is equipped with a digital servo feedback with an integrated multi-turn absolute encoder that has data storage capability which records the motor parameters to allow for damage-free motor operation. It also has a detection range of 4096 motor revolutions with absolute position detection. The standard housing aids in maintaining optimal ambient temperatures of 0 to 45 degrees Celsius. The power connector on the MDD112C-N-030-N2M-130PA0 motor is located on side A. The cable that will be connected to the power can be ordered in a maximum length of 75 meters. Ensure that the spigot nuts on the connectors (power and feedback) are screwed in tightly when connecting.

With a standard centering diameter of 130mm, the MDD112C-N-030-N2M-130PA0 servo motor is driven by an output shaft with keyway which is sealed to provide exceptional performance in poor environmental conditions. It falls into the N balance class that is used in normal applications. Continuous torque at standstill is 28 Nm, continuous current at standstill is 43.4 Amps, and the operation peaks at 166.4 Amps. The constant torque at 20 degrees Celsius is 0.65 Nm/A.

Prevent motor damage by lifting and handling the motor correctly. Avoid impacts to the motor and use suitable lifting devices fitted to the correct points when moving the motor. Install and operate the servo motor at an elevation no higher than 1000 meters and a temperature no higher than 45 degrees Celsius. The MDD112C-N-030-N2M-130PA0 motor is coated in a black protective prime coat. This product is available from Wake Industrial with a one-year warranty period.

MDD112C-N-030-N2M-130PA0 Documents

  • MDD112CN030N2M130PA0
  • mdd112c-n-030-n2m-130pa0
  • MDD112C N 030 N2M 130PA0

MDD112C-N-030-N2M-130PA0 Technical Specifications

Blocking Brake: Not Equipped
Housing Design : Standard
Motor Feedback: Multiturn Absolute
Nominal Speed: 3000 Min
Output Shaft: With Shaft Sealing
