MDD093C-N-030-N5M-110GB2
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The MDD093C-N-030-N5M-110GB2 is a Bosch Rexroth Indramat synchronous motor with a nominal speed of 3000 min-1 and a protection category of IP65. Part of the MDD Synchronous Motors Series, it features a continuous torque at standstill of 19.5 Nm. The motor supports surface cooling and weighs 36 kilograms.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Bosch Rexroth Indramat part number MDD093C-N-030-N5M-110GB2 from MDD Synchronous Motors is made for manufacturing automation systems.
This motor type works reliably in multiple automation setups while meeting the needs of automated machines and production machinery. Thanks to its 3000 min⁻¹ rated speed, the motor generates 19.5 Nm of continuous torque from a stationary position to provide stable power output. The engine has a maximum achievable torque output of 60.6 Nm to deal with both regular and peak operating conditions effectively. This system handles dynamic load fluctuations efficiently thanks to its 17.3 A standstill power supply and peak current capability of 55.3 A. The 61 x 10⁻⁴ kg·m² moment of inertia in the rotor promotes precise movement during start-ups and coasting cycles. Its electrical parameters at 20 °C include a torque production of 0.61 Nm per Ampere while working with 0.66 Ω of resistance and 6.8 mH of inductance to optimize energy consumption and control performance stability.
The motor holds its heat for 100 minutes with its cooling structure to support long periods of operation without temperature problems. The designed motor system uses natural airflow and surface cooling to deliver maximum heat energy efficiency. The device works properly from 0 degrees Celsius through 45 degrees Celsius and holds an IP65 rating, which protects it against dust and water jet entry. The MDD093C-N-030-N5M-110GB2 motor handles even the most demanding automation work thanks to its weight of 36 kg and advanced performance design. It can be purchased at Wake Industrial with a one-year warranty.
Frequently Asked Questions about MDD093C-N-030-N5M-110GB2:
Q: What is the torque output of the MDD093C-N-030-N5M-110GB2 motor?
A: The MDD093C-N-030-N5M-110GB2 provides 19.5 Nm of continuous torque and up to 60.6 Nm of peak torque, enabling reliable performance under dynamic load conditions.
Q: What is the rotor inertia and electrical configuration of the MDD093C-N-030-N5M-110GB2?
A: The motor features a rotor moment of inertia of 61 x 10⁻⁴ kg·m², with 0.66 Ohm resistance, 6.8 mH inductance, and 0.61 Nm/A torque constant at 20°C.
Q: What are the speed and current ratings of the MDD093C-N-030-N5M-110GB2?
A: This motor operates at 3000 min⁻¹ rated speed, with a standstill current of 17.3 A and peak current capacity of 55.3 A.
Q: How does the MDD093C-N-030-N5M-110GB2 manage thermal performance?
A: It uses natural airflow and surface cooling, sustaining thermal stability with a 100-minute time constant for long operation periods.
Q: What protection and environmental specs does the MDD093C-N-030-N5M-110GB2 meet?
A: The MDD093C-N-030-N5M-110GB2 meets IP65 protection standards and operates effectively from 0°C to 45°C, making it suitable for harsh industrial conditions.
