CB1061-0001
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
Available
The CB1061-0001 is an industrial ATX mainly used by Beckhoff,with the Intel® Q87 PCH chipset the LGA1150 socket Intel® 4th Generation Core™ and Celeron® processors. It has DDR3L-1600 RAM support with up to 32 GB via the two SO-DIMM204 sockets. The features of CB1061 are as follows: three PCI slots, two PCIe-x1 slots, one PCIe-x4 slot, and one PCIe-x16 slot. It has dual Gigabit Ethernet, six SATA II interfaces with a 6 Gbps data transfer rate, 10 USB 2.0 and 4 USB 3.0 interfaces provide high connectivity. Video outputs are DVI, HDMI, DisplayPort, and VGA, and HDA sound with SPDIF and GPIO support means this is an ideal board for complex industrial devices.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Beckhoff CB Motherboard CB1061-0001 industrial ATX motherboard is a highly efficient and reliable product meant for use in different automation as well as control applications. This motherboard is based on Intel® Q87 PCH chipset and LGA1150 socket and supports Intel® 4th Generation Core™ and Celeron® processors providing sufficient processing capabilities for application in Industrial systems. The basic specifications for the CB1061-0001 are DDR3L-1600 RAM that can handle up to 32 GB via two SO-DIMM204 slots. This high memory capacity is also very suitable for applications where multiple tasks are run at the same time and where high-speed data processing is crucial, and the processors will not slow down because of the sheer load that is being imposed on them.
Specifically, the CB1061-0001 is characterized by connectivity. It has three PCI slots, two PCIe by 1, one PCIe by 4 and one PCIe by 16 for expansion of other slots for cards and peripherals. In terms of the LAN offers two Giga Ethernet ports for network, while SATA II interfaces available six which provide the faster data rate of 6Gbps for storage devices. Having to do with the connectivity with external devices, the model CB1061-0001 has access to 14 USB ports: 10 USB 2.0 and 4 USB 3.0 ports for the connection of various peripherals. Video outputs are also abundant, that include DVI, HDMI, DisplayPort, and VGA, this makes flexibility in display possible.
Further, the motherboard is equipped with High-Definition Audio (HDA) with SPDIF; and GPIO pins for connecting the sensors and others. On this basis, the CB1061-0001 is well suitable for complex application such as industrial devices that need stable performance and connection in complex conditions.
Frequently Asked Questions about CB1061-0001:
Q: What processors are compatible with the CB1061-0001?
A: It supports Intel® 4th Generation Core™ and Celeron® processors using the LGA1150 socket.
Q: What is the maximum RAM capacity?
A: The motherboard supports up to 32 GB of DDR3L RAM.
Q: How many expansion slots are available?
A: It includes three PCI slots, two PCIe-x1, one PCIe-x4, and one PCIe-x16 slot.
Q: What types of connectivity does it offer?
A: The CB1061-0001 features dual Gigabit Ethernet, six SATA II interfaces, 14 USB ports, and various video outputs.
Q: What video output interfaces are supported?
A: It supports DVI, HDMI, DisplayPort, and VGA connections.
