P22NRXA-LSN-NS-02

  • Rated 4.6 (31 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
    In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options

The P22NRXA-LSN-NS-02 is manufactured by Pacific Scientific as part of the Powermax II P stepper motor series. It features a thermal resistance of 6.6 Mounted °C/Watt and rotor intertia of 0.025(kg-m²x10¯³). These are the most powerful stepper motors with a holding torque of .42 Nm and a detent torque of .018 Nm.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The P22NRXA-LSN-NS-02 is one of the hybrid stepper motors from the well-known manufacturer Pacific Scientific. It has a two-stack laminated rotor. This device generates both torque producing and non-torque producing flux during operation. The flux gets directed towards the stator when the device is energized. The unit features an octagonal housing and an all-in-one molded stator assembly. The downtime of the product is greatly reduced due to the enhanced heat dissipation. The motor is also capable of performing quite efficiently at high speed. The polymer end bell increases the flexibility of the device. The unit has a 2.25-inch size across flats.

The motor has an IP 23 protection rating. The device encompasses a special shaft with a smooth style. It can be put to use for any application. The unit has no encoder or provisions for mounting an encoder. The product has a regular-style construction encased in a NEMA 23 frame. The honed inner diameter of the stator and the precision-ground outer diameter of the rotor collectively produce a concentric air gap. The motor features high-tech polymer for the electrical connector and encapsulated windings. The stepper device comes with a one-year warranty.

The hybrid motor is capable of withstanding a maximum radial load of 20lbs on its shaft. This is the load in the middle of the normal shaft extension. The two-phase device has a full step angle of 1.8° and completes 200 full steps in one revolution. The unit is marketed under the POWERMAX II brand name and has an economical motor design. The motor has a sequence number of 02. The NEMA 23 size product comes with a NEMA type mounting option. This device also features an A-type winding that makes it apt for all applications. The stepper motor can be shipped to any address through our delivery partners including UPS and FedEx.

  • P22 NRXA LSN NS 02
  • P22-NRXA-LSN-NS-02
  • P22NRXA LSN NS 02
  • P22NRXA-LSN-NS-O2
  • P22NRXALSNNS02
  • P22NRXALSNNSO2

P22NRXA-LSN-NS-02 Technical Specifications

Axial Force: 58N
Radial Force: 89N
Weight: 1.13 kg
Type: Standard
Thermal Resistance: 6.6 Mounted °C/Watt
Rotor Inertia: 0.025(kg-m²x10¯³)
Holding Torque: .42 Nm
Detent Torque: .018 Nm
Encoder Option/Sequence Number: No Feedback/Factory Assigned
Size: NEMA 23
Number of Stacks: 2 Stacks
Mounting: NEMA
Construction: Regular
Termination: Receptacle
Winding Type: per assigned letter
Rotor Type: Standard
Shaft Configuration/Shaft Modifications: Special/Smooth
