SR3662-8292-2-48B

  • Rated 4.4 (18 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options
Permanent Magnet DC Motor Series manufactured by Pacific Scientific. This motor features a Voltage (DC) of 90 and a Current (Amps) of Factory Assigned.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

SR3662-8292-2-48B

  • Rated 4.4 (18 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options
Permanent Magnet DC Motor Series manufactured by Pacific Scientific. This motor features a Voltage (DC) of 90 and a Current (Amps) of Factory Assigned.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a SR3662-8292-2-48B to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

When it comes to motion control solutions, Pacific Scientific seems to have gained the top spot in the market. Pacific Scientific Permanent Magnet DC Motors have been known for rugged construction, high value and unmatched performance for over 50 years. The PMDC motors are available with two year manufacturer’s warranty, plus they are customized for all types of servo drives and PLC systems. The part number SR3662-8292-2-48B is one example of high-performance continuous duty motors from Pacific Scientific. The motor belongs to SR branch of the continuous duty motors’ series.

To start with, the SR3662-8292-2-48B represents PMDC motor models that have gained acclamations from different certification bodies, so it’s safe to use almost anywhere. The permanent magnet motor model features NEMA C face and has removable base. The permanent magnet replaces wound field design to improve efficiency by making the motor lighter in weight and more compact. The length of the SR3662-8292-2-48B is 10.13 inches and it weighs around 10kgs. Like other SR series models, this PMDC motor features TENV (non-vented) enclosure. It offers a continuous current of 3.5A while its continuous torque is 12lb-inch. The motor’s peak current is found to be 71A while its inertia is 5.0 lb-inch. The SR3662-8292-2-48B is a 90Vdc motor with 1/3 HP power output, while it can reach up to 1750 RPM top speed.

The PMDC motor features H-Class insulation, rugged fused commutator, explosion proof body, anti-cogging magnets, polyester impregnated armature, all making it one durable and high-performance model. Pacific Scientific SR3662-8292-2-48B PMDC motor has been recognized by underwriter laboratories (UL1004) while having CSA standard C22.2 certificate, and CE marking as well. All in all, the SR3662-8292-2-48B is a combination of durable and energy-efficient components to make it good solution for different types of servo systems.

  • SR3662 8292 2 48B
  • SR36628292248B

SR3662-8292-2-48B Technical Specifications

Product Code: Factory Assigned
Voltage (DC): 90
Enclosure: Factory Assigned
Current (Amps): Factory Assigned
H.P.: 1/3
RPM: Factory Assigned
