The AKM44G-ACCN2-00 is a synchronous servo mobtor under the AKM range of Kollmorgen motors. It falls under the AKM4 family that has a flange size of 84mm and a torque range of 4.7 to 14.4Nm. This type is designed to be used for drives for industrial packaging machines, robots, textile, and printing machines that require high levels of dynamics. The AKM44G-ACCN2-00 is driven explicitly by SERVOSTAR amplifiers used for speed and torque control. It is installed as a component of an electric apparatus or machine and can only be brought to operation as an integral part of the machine.
Avoid connecting the motor directly to the mains supply. It comprises of a 4 rotor length, G winding type, IEC flange, shaft with keyway, and 0.5m shielded cables with IP 65 connector and angular connectors. The feedback on this motor is a Comcoder with 2048 PPR. When used with a servo amplifier it becomes ideal for positioning tasks in textile and transfer lines, among other applications. It is ideal for demanding servo applications across the factory floor. The AKM44G-ACCN2-00 comes with high energy permanent magnets in the rotor with rare earth neodymium-iron-boron materials.
They enable the servo amplifier to control the brushless motor dynamically. The amplifier mitigates the need for brushes since it conducts commutation electrically. An electrically isolated thermistor is used to measure the temperature of the windings. General technical data includes an ambient temperature of 5 to 40 degrees, 3K3 climate category, a maximum installation altitude of 1000 meters, and 96% permissible humidity. The ball-bearing life of the AKM44G-ACCN2-00 is 20,000 operating hours. You can mount this motor using three ways. Shaft end upwards, shaft end downwards, or shaft end A-side.
|Max BUS (VDC):||640|
|Max Rated N:||6000|
|Max Rated Power at Max BUS:||1.73 kW|
|Max Stall Tc:||6.0 Nm|
|Max Tp:||20.4 Nm|
