AKM43E-GCC2R-00

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKM43E-GCC2R-00 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 20.4 Nm. The AKM series also featured a max rated force of 6000 and max rated power of 1.73 kW.

AKM43E-GCC2R-00

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKM43E-GCC2R-00 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 20.4 Nm. The AKM series also featured a max rated force of 6000 and max rated power of 1.73 kW.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKM43E-GCC2R-00 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Kollmorgen is a world-leading producer of state-of-the-art motion systems. They range from drives, amplifiers, servo motors, stepper motors, and more. They are a staple in most factories thanks to their ability to increase productivity and improve machine effectiveness. The AKM43E-GCC2R-00 is a servo motor under the AKM series. They are designed to offer services for a wide array of applications. When combined with Kollmorgen’s AKD servo drives, they present you with a cost-effective system with faster delivery time. Like other AKM motors, the AKM43E-GCC2R-00 features low cogging, 47% more shaft power and stellar motor power density.

The AKM43E-GCC2R-00 is designed to offer flexibility to meet your specific needs thanks to its wide range of mounting orientations, feedback, connectivity, and other options. It comprises of smooth performance owing to its low-harmonic distortion magnetic designs. The motor meets CE, UL, and CSA requirements and it comes with built-in thermistors to mitigate thermal overload. Some of the options available include connectivity, custom windings, shaft variations, and holding brakes. Since it falls under the AKM4 frame size, it comprises of SFD feedback and a D motor-mounted rotatable single connector. Thanks to Kollmorgen's innovative technology, the AKM43E-GCC2R-00 provides you unmatched customization, numerous flange options, and feedback options for rugged environments.

The AKM43E-GCC2R-00 servo motor features 4.70Nm continuous torque, 2.76Arms continuous current, and 640Vdc maximum rated DC Bus voltage. Its maximum mechanical speed is 6000rpm, peak current is 11.0Arms, and peak torque is 15.9Nm. The motor weighs 4.35kg and has static friction of 0.038Nm. It comprises of an 84mm flange size, E winding type, and alternative IEC standard flange. There is an optional 24 V holding brake, shaft with keyway, and 3 rotor length.

  • AKM-43E-GCC2R-00
  • AKM43E-GCC2R-OO

AKM43E-GCC2R-00 Technical Specifications

Frame Size: AKM4
Frame Size:
Max BUS (VDC): 640
Max Rated N: 6000
Max Rated Power at Max BUS: 1.73 kW
Max Stall Tc: 6.0 Nm
Max Tp: 20.4 Nm
Stack Length: 3
