AKM42G-KKDNCA-00

  • Rated 4.5 (35 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships 1-2 Days
  • Call for Expedited Shipping and Product Condition Options
The AKM42G-KKDNCA-00 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 20.4 Nm. The AKM series also featured a max rated force of 6000 and max rated power of 1.73 kW.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock! AKM42G-KKDNCA-00

AKM42G-KKDNCA-00

  • Rated 4.5 (35 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships 1-2 Days
  • Call for Expedited Shipping and Product Condition Options
The AKM42G-KKDNCA-00 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 20.4 Nm. The AKM series also featured a max rated force of 6000 and max rated power of 1.73 kW.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a AKM42G-KKDNCA-00 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Kollmorgen is an engineering firm known for providing sophisticated solutions to the PLC and robotics industries in Europe and North America. The part number AKM42G-KKDNCA-00 represents a popular series of synchronous servomotors that’s been divided into seven size categories. The AKM series features lightweight brushless servos, which produce industry-leading power, speed, and torque. The AKM4 models feature a flange size of 84mm, and their standstill torque lies in the range of 1.95 Nm to 6.0 Nm.

The AKM42G-KKDNCA-00 servomotor by Kollmorgen features a rotor length of 2-stack, which means, more room for neodymium-iron-boron magnet. This, in turn, means much better motor dynamics. The neodymium-iron-boron material is a rare-earth magnet that is capable of amplifying energy at a low voltage. The AKM servo motor is available in three different voltage variants; 230V, 400V, and 480V. The 230V variant offers a rated power of 1.06 kW, while the 480V variant delivers up to 1.5 kW. This particular model has a rated speed of 6000 RPM and a peak speed of 7500 RPM. The servomotor features a standstill torque of 3.53 Nm while its maximum torque is 11.5 Nm.

The AKM42G-KKDNCA-00 brushless synchronous motor weighs 3.39 kilograms. It features a shaft with an open keyway to ensure a smooth transfer of power, speed, and torque. The servo motor features a single angular connector with a fully digital resolver interface. The resolver comes without a brake. The motor itself comes without a holding brake. It is recommended that the servomotor should be used along with a SERVOSTAR servo amplifier to get the best results.

  • AKM-42G-KKDNCA00
  • AKM42G-KKDNCAOO

AKM42G-KKDNCA-00 Technical Specifications

Frame Size: AKM4
Max BUS (VDC): 640
Max Rated N: 6000
Max Rated Power at Max BUS: 1.73 kW
Max Stall Tc: 6.0 Nm
Max Tp: 20.4 Nm
Stack Length: 2
