AKM22E-BNM2EM-00

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKM22E-BNM2EM-00 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 4.82 Nm. The AKM series also featured a max rated force of 8000 and max rated power of .54 kW.

AKM22E-BNM2EM-00

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKM22E-BNM2EM-00 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 4.82 Nm. The AKM series also featured a max rated force of 8000 and max rated power of .54 kW.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKM22E-BNM2EM-00 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Kollmorgen has a great reputation for producing top tier PLC systems. The company showcases high-tech and compact tools for industry-leading brands around the world. The AKM series of brushless servomotors is divided into seven categories on the basis of flange size and torque output. The series offers a wide variety of motors that offer standstill torque in the range of 0.1 Nm to 60 Nm.

The part number AKM22E-BNM2EM-00 belongs to the AKM servo motor series introduced by Kollmorgen in 2003. The AKM22E-BNM2EM-00 servo motor is meant for low-speed and low-torque operations. The standstill torque of the servomotor is 0.87 Nm while its standstill current is 2.73 amperes. The torque peaks at 2.76 Nm while the maximum current of the motor is 10.9 amperes. The brushless has a phase to phase resistance of 5.09 ohms. It has a winding inductance of 9.7 mH. Other important mechanical data includes; 0.16 kg per squared centimeters of rotor inertia and 1.1 kg of weight.

The AKM22E-BNM2EM-00 DC motor by Kollmorgen features a 58mm flange and its rotor length is 2. The servomotor has a winding type E and its construction conforms to the NEMA standards. There is a smooth shaft that can accommodate a radial load of 145 N at 5000 RPMs and an axial load of 60 N at the same speed. The brushless servo motor is supplied with a 0.5m shielded cable that features IP20 connectors. Low rotor inertia accounts for quick start/stop on most motors but with the AKM22E-BNM2EM-00, a 24V holding brake is supplied along with the motor. This motor comes with no additional customization features.

  • AKM-22E-BNM2EM00
  • AKM22E-BNM2EMOO

AKM22E-BNM2EM-00 Technical Specifications

Frame Size: AKM2
Frame Size:
Max BUS (VDC): 640
Max Rated N: 8000
Max Rated Power at Max BUS: .54 kW
Max Stall Tc: 1.4 Nm
Max Tp: 4.82 Nm
Stack Length: 2
