The AKM13D-BNSNR-02 Is manufactured by Kollmorgen and features a max BUS of 320 and max Tp of 1.46 Nm. The AKM series also featured a max rated force of 8000 and max rated power of .30 Kw.

AKM13D-BNSNR-02

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKM13D-BNSNR-02 Is manufactured by Kollmorgen and features a max BUS of 320 and max Tp of 1.46 Nm. The AKM series also featured a max rated force of 8000 and max rated power of .30 Kw.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKM13D-BNSNR-02 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The AKM13D-BNSNR-02 synchronous servomotor is one of the several AKM series of motors from Kollmorgen. The servomotor is equipped with rare magnets made of a combination of neodymium, iron, and boron in its rotor. These magnets make the motor suitable for use in highly dynamic environments. The motor is fitted with a nameplate and comes with an inbuilt resolver as the standard feedback element. The position of the resolver is analyzed by a SERVOSTAR digital servo amplifier. The stator is integrated with a three-phase winding. The DC brushless motor has a one-year warranty period.

The stator windings encompass temperature sensors that monitor the temperature of the windings. The motor has 95% relative permissible humidity without condensation. It also has 1%/K power derating between 40°C and 50°C. The unit must be installed at a maximum height of 1,000 meters above sea level. The motor has a rotor length of 1 and a flange size of 1 equivalent to 40mm and a winding type of D. The flange is designed as per NEMA specifications. It encompasses a smooth shaft and a special connector. The resolver used for feedback features a two-pole hollow shaft and has leads with less than 120pF/m capacity. It makes use of 4 x 2 x 0.25mm2 shielded cables.

The motor has a polyurethane sheathing with a 11Y identification code and a polyterephthalate core insulation with a 12Y identification code. The rotor of the motor should revolve freely without any grinding noise. The servo unit has a power rating of 0.08kW at 75VDC and a thermal time constant of 7 minutes. It encompasses a voltage constant of 10.9mVmin and a torque constant of 0.17Nm/A. We can ship the customized motor to any address worldwide through our trusted global delivery partners.

  • AKM-13D-BNSNR-02
  • AKM13D-BNSNR-O2

AKM13D-BNSNR-02 Technical Specifications

Frame Size: AKM1
Frame Size:
Max BUS (VDC): 320
Max Rated N: 8000
Max Rated Power at Max BUS: .30 Kw
Max Stall Tc: .409 Nm
Max Tp: 1.46 Nm
Stack Length: 3
