MAD160C-0100-SA-M2-AH0-35-N1

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911328837
  • Stock: Call for Quote
MAD160C-0100-SA-M2-AH0-35-N1 Spindle Motor manufactured by Rexroth, Indramat, Bosch. This motor has a cooling mode with an Axail Fan, Blowing and a Multiturn Absolute, 2048 increments encoder. It also has a mounting style of Flange and a Standard bearing.

MAD160C-0100-SA-M2-AH0-35-N1

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911328837
  • Stock: Call for Quote
MAD160C-0100-SA-M2-AH0-35-N1 Spindle Motor manufactured by Rexroth, Indramat, Bosch. This motor has a cooling mode with an Axail Fan, Blowing and a Multiturn Absolute, 2048 increments encoder. It also has a mounting style of Flange and a Standard bearing.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MAD160C-0100-SA-M2-AH0-35-N1 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MAD160C-0100-SA-M2-AH0-35-N1 is an explosion-proof asynchronous servomotor in the MAD series from Bosch Rexroth. The motor must be commissioned only in a system along with an Ex-p controller to purge it. The device must be checked for visible damage to its components before installation. It supports B35 type foot assembly with M12 screws and through 14mm mounting holes. The insertion fitting must not have any damage to the system side. The motor must be connected using standard tools such as an adjustable torque screwdriver, a torque wrench with an adjustable scale, a set of combination wrenches and Allen keys as well as a socket wrench set.

The servomotor features a terminal type clamping mode for its equipotential bonding conductor. The output direction of the fan cowl can be set to any of the four directions. The device has a size of 160, a length of C and a winding type of 0100. It is fitted with an EnDat 2.1 multi-turn absolute encoder with 2,048 signal periods. The unit has a rotatable terminal box on its B side for its electrical connection and a smooth shaft without a shaft seal ring. The motor is also fitted with standard bearings and features a vibration severity of A in accordance with DIN EN 60034-14 specifications. It has a moment of inertia of 0.311kgm2.

The asynchronous device encompasses an insulation class of 155 according to DIN EN 60034-1 specification and IP 65 protection rating as per DIN EN 60034-7 specifications. The unit has a maximum speed of 6,000RPM, a maximum torque of 530Nm and a maximum current rating of 112.3A. The air hose has a connection diameter of 150mm. The motor is available with a one-year warranty period. It can be sent to the address of your choice through our trusted global shipping partners.

MAD160C-0100-SA-M2-AH0-35-N1 Documents

  • MAD160C0100SAM2AH035N1
  • mad160c-0100-sa-m2-ah0-35-n1
  • MAD160C 0100 SA M2 AH0 35 N1

MAD160C-0100-SA-M2-AH0-35-N1 Technical Specifications

Bearing: Standard
Cooling Mode: Axail Fan, Blowing
Encoder: Multiturn Absolute, 2048 increments
Mounting Style: Flange
