HCS04.2E-W0640-N-04-NNNN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911325456
  • Call for Expedited Shipping and Product Condition Options
The HCS04.2E-W0640-N-04-NNNN Compact Converter is manufactured by Rexroth Indramat Bosch. This converter has an Internal Air cooling mode and a 640A Maximum Current. This compact converter also comes with a 380…480V Direct Power Supply and has a 132kW...500kW Power Range.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

HCS04.2E-W0640-N-04-NNNN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911325456
  • Call for Expedited Shipping and Product Condition Options
The HCS04.2E-W0640-N-04-NNNN Compact Converter is manufactured by Rexroth Indramat Bosch. This converter has an Internal Air cooling mode and a 640A Maximum Current. This compact converter also comes with a 380…480V Direct Power Supply and has a 132kW...500kW Power Range.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a HCS04.2E-W0640-N-04-NNNN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth builds drives for industries that make use of hydraulic, electronic and mechanical components so that controlling machines, that are necessary in the varying industries, can be done in a smooth, easy and effective manner.

The HCS04.2E-W0640-N-04-NNNN is a control drive part from the class of HSC04.2E with a converter that uses a typical motor power of 250/200 KW, a continuous output power of 268/333 V, a storage or transport temperature of -25 … + 70 ◦C, and an installation altitude with its maximum installation set at the of 3000 m. The installation altitude also goes up to 1,000 m, above derating by 1% per 100m.The allowed pollution degree is 2 in accordance with the EN 61800-5-1. Furthermore, the operating temperature is -10 … +40 ◦C when sized with both high and continuous overload. Note that all these results are calculated at 3AC 400 V mains voltage and fs = 4 KHz switching frequency.

The HCS04.2E-W0640-N-04-NNNN itself uses a high overload pre-conduit fuse of 500 A or a Cu cable of 2 x (3 x 150) mm2, a mains fuse converter protection of 500 A sf D, and a lines in control cabinet of 2 x 120 mm2 per phase while in the high continuous load, it makes use of a pre-conduit fuse of 630 A or a Cu cable of 2 x (3 x 185) mm2, a mains fuse converter protection of 630 A sf E, and a lines in control cabinet of 2 x 150 mm2 per phase. The HCS04.2E-W0640-N-04-NNNN also makes use of the Class J 600 A max. of the UL fuses 600 V type which are known to be extremely fast acting.

HCS04.2E-W0640-N-04-NNNN Documents

  • HCS042EW0640N04NNNN
  • hcs04.2e-w0640-n-04-nnnn
  • HCS04 2E W0640 N 04 NNNN

HCS04.2E-W0640-N-04-NNNN Technical Specifications

Cooling Mode: Internal Air
Direct Power Supply: 380…480V
Maximum Current: 640A
Power Range: 132kW...500kW
