CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW

  • Rated 4.5 (33 total ratings)
  • MPN: R911310273
  • Call for Expedited Shipping and Product Condition Options
The CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW control unit is manufactured by Bosch Rexroth Indramat. The unit utilizes SERCOS Interface as its form of master communication, and it is equipped with the Encoder EnDat 2.1/1Vpp/TLL interface option.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW

  • Rated 4.5 (33 total ratings)
  • MPN: R911310273
  • Call for Expedited Shipping and Product Condition Options
The CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW control unit is manufactured by Bosch Rexroth Indramat. The unit utilizes SERCOS Interface as its form of master communication, and it is equipped with the Encoder EnDat 2.1/1Vpp/TLL interface option.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

One of the components of the Rexroth IndraDrive drive system is the drive controller. It has two essential parts: the control section and the power section. The control sections in the CDB family are double-axis types where the functionality of two digital axes is integrated into one unit. As part of its drive controller, the CDB control section is used in machine tools, food and packaging machines, and handling and mounting systems.

The CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW is a Bosch Rexroth control section model in the CDB series. It features three encoder evaluation interfaces designed for encoder systems with a supply voltage of 5V. Examples of such encoders are the 5V-TTL square-wave encoder with reference track, the sin-cos encoder (1 Vpp) with EnDat 2.1 and Sense lines, and the sin-cos encoder (1 Vpp) with reference track. The configurable control section is also equipped with a SERCOS master communication module for signal transfer to higher-level control units. This transfer is facilitated by fiber optics cables, which can be ordered separately from the manufacturer.

Using the standard control panel that comes with the CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW, users can set the drive address, navigate through the error memory, and establish the position data reference. In addition, they can set the transmission power and field bus transmission rate of the SERCOS module. The available safety option in this control section is Safety Technology I/O. It allows application-related functions like safety-related standstill, safety-related drive interlock, and safety-related direction of motion. Firmware can be used here, but it must be ordered as a separate sub-item. The typical inrush current of the control section is 6A, while its maximum pulse width value is 60ms. This product can be shipped globally with a one year warranty period from Wake Industrial.

  • CDB011CSEEN2EN2EN2NNNS1SNNFW
  • CDB01 1C SE EN2 EN2 EN2 NNN S1 S NN FW
  • cdb01.1c-se-en2-en2-en2-nnn-s1-s-nn-fw

CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW Technical Specifications

Master Communication: SERCOS Interface
Option 1: Encoder EnDat 2.1/1Vpp/TLL
Option 2: Encoder EnDat 2.1/1Vpp/TLL
Option 3: Encoder EnDat 2.1/1Vpp/TLL
