MHD112A-024-PP1-BN

  • Rated 4.5 (25 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911288685
  • Stock: In-Stock, Ships Today
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MHD112A-024-PP1-BN Magnet Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 24 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is With Key and it is Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock! MHD112B-048-NP0-BN | Rexroth, Indramat, Bosch MHD Motor Series | Image

MHD112A-024-PP1-BN

  • Rated 4.5 (25 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911288685
  • Stock: In-Stock, Ships Today
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MHD112A-024-PP1-BN Magnet Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 24 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is With Key and it is Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a MHD112A-024-PP1-BN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch Rexroth MHD112A-024-PP1-BN is a synchronous servo motor. As per the motor type code, the code for the motor frame size is 112, the code for the motor frame length is A and the code for the motor winding is 024. The MHD112A-024-PP1-BN is a flange mounted motor. There are four holes on the flange through which screws can be inserted for securing the motor. The size of the motor flange is 192 millimeters. The motor dimensions include 130 millimeters centering diameter, 309 millimeters motor length is 40 millimeters shaft diameter. The shaft on the MHD112A-024-PP1-BN features a keyway and a sealing ring. The shaft seal wears during operation and should be inspected on a periodic basic. The MHD112A-024-PP1-BN is IP65 rated and can be installed close to operating machinery. This helps to reduce the cost of maintenance and reduces the total cost of system ownership.

The MHD112A-024-PP1-BN motor supports digital servo feedback with integrated multiturn absolute encoder. This motor features allows the motor to send feedback to the drive controller. The power connector on the motor is on side B of the housing. The MHD112A-024-PP1-BN includes a 22 Nm rated holding brake. The function of the holding brake is to hold the motor shaft and prevent its rotation. The brake releases the motor shaft when a 24 Volts DC release signal is applied. The MHD112A-024-PP1-BN is suited to natural convection or surface cooling. The recommended ambient temperature is 0 to 40 degrees Celsius. The maximum speed of the motor is 4000 RPM. The mass of the motor is approximately 23 kilograms. The surface of the motor is coated with prime black coat (RAL 9005).

MHD112A-024-PP1-BN Documents

  • MHD 112A 024 PP1 BN
  • MHD 112A-024-PP1-BN
  • MHD-112A-024-PP1-BN
  • MHD112A-O24-PP1-BN
  • MHD112A024PP1BN
  • MHDII2A-024-PPI-BN
  • MHD112A 024 PP1 BN
  • mhd112a-024-pp1-bn

MHD112A-024-PP1-BN Technical Specifications

Driven Shaft: With Key
Holding Brake: Equipped
Motor Encoder: Multiturn
Product Group: MHD
Winding Code: 24
Motor Frame Size: 192mm Flange Size, 130mm Centering Diameter
Motor Frame Length: 15.0 Nm
Winding Code: 024
Motor Encoder: Digital servo feedback with integrated multiturn absolute encoder
Output Shaft: Shaft with keyway according to DIN 6885-1 (with shaft sealing ring)
Holding Brake: 22,0 Nm holding brake
Output Direction of Power Connector: Output connector in direction of side B
Housing Type: For liquid cooling
